MULTICOMP-PRO 2MD6T1B5M2RE Double-Pole Double-Throw Switch
The 2MD6T1B5M2RE is a durable double-pole double-throw switch designed for industrial use. It features a stainless steel housing and epoxy sealing for reliability in harsh environments. The switch has a chrome-plated brass actuator and a nickel-plated brass bushing, with tin-plated brass support. It offers a contact resistance of 20mΩ at 2-4V DC, insulation resistance of 1000MΩ, and dielectric strength of 1000V rms at sea level. Operating temperatures range from -30°C to +85°C, making it ideal for various switching applications.
MULTICOMP-PRO 2MD6T1B5M2RE Double-Pole Double-Throw Switch Specifications:
- Contact Resistance: 20mΩ max. at 2 to 4V DC
- Mechanical Life: 30,000 cycles
- Dielectric Strength: 1000V rms at sea level
- Operating Temperature: -30°C to +85°C
- Materials: Case and Bushing - stainless steel, Actuator - chrome-plated brass, Bushing - nickel-plated brass, Housing - stainless steel, Support - tin-plated brass
- Impact Resistance: Epoxy-sealed for durability
- Insulation Resistance: 1000MΩ
- Maximum Contact Rating: 0.4 VA at 20V (AC/DC)
Buy the multicomp Series DPDT Toggle Switch: 2MD6T1B5M2RE
Purchase the multicomp Series DPDT toggle switch 2MD6T1B5M2RE online and enhance your electrical setups with this high-quality, epoxy-sealed, stainless steel switch. Its durable construction and high dielectric strength ensure consistent performance in demanding environments. Featuring a chrome-plated brass actuator and nickel-plated brass bushing, this switch supports multiple switching modes, including On-On-On, making it perfect for industrial automation, control panels, and machinery. Order now for fast delivery and dependable operation.
Order your multicomp Series DPDT toggle switch 2MD6T1B5M2RE today and equip your projects with reliable, industrial-grade switching performance.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO 2MD6T1B5M2RE?
You can click on the BUY or RFQ button to purchase 2MD6T1B5M2RE from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part 2MD6T1B5M2RE?
You can download the 2MD6T1B5M2RE datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of 2MD6T1B5M2RE?
MULTICOMP-PRO
