MULTICOMP PRO 698120 D-Sub Connector
The 698120 is a 25-pin D-subminiature connector featuring gold-over-nickel plated brass contacts, a solder cup termination, and a tin-plated steel shell. It is designed with PBT and glass-fiber reinforced insulation and includes EMI/RFI shielding. This connector supports a rated current of 5A at 25°C, with a maximum contact resistance of 15 milliohms and a minimum insulation resistance of 5000 megaohms. It can withstand a dielectric voltage of 1000V AC for one minute and operates across a temperature range of -55°C to +105°C. Suitable for industrial, communication, and networking applications.
MULTICOMP PRO 698120 D-Sub Connector Specifications:
- Current Rating: 5 Amps at 25°C
- Insulation Resistance: 5000 MΩ minimum at 500 V DC
- Dielectric Withstanding Voltage: AC 1000V minimum for 1 minute
- Contact Resistance: 15 mΩ maximum mated
- Operating Temperature: -55°C to +105°C
- Insulator Material: PBT and Glass-Fibre reinforced
- Contact Material: Brass, Gold over Nickel, Tin plated solder cup
- Shell Material: Steel, Tin plated
- Working Voltage: 250 Vrms
- Dimensions: Refer to detailed table (e.g., length varies with model, typical diameter approx. 6.4 mm)
Buy the Multicomp Series D-Sub Connector: 698120
Purchase the Multicomp D-Sub Connector model 698120 online today to enjoy superior signal integrity and industrial-grade durability. With gold-over-nickel plated contacts, tin-plated steel shell, and EMI/RFI shielding, this connector ensures reliable data transmission in demanding environments. Supports 5A current at 25°C, withstands voltages up to 1000V AC, and operates across a wide temperature range from -55°C to +105°C. Ideal for industrial control, communications, and networking applications—order now for fast delivery and technical support.
Buy Multicomp 698120 now and experience unmatched reliability and performance with robust EMI/RFI shielding and durable solder cup termination.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 698120?
You can click on the BUY or RFQ button to purchase 698120 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 698120?
You can download the 698120 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 698120?
MULTICOMP PRO
