MULTICOMP PRO 7030087 Green LED Lamp
The 703-0087 is a 3mm round green LED lamp featuring a green water-clear lens. It utilizes a GaP/GaP chip housed in clear epoxy resin, offering a power dissipation of 78mW, a viewing angle of 30 degrees, and a luminous intensity of 50 millicandelas. Suitable for LED lighting applications, this component is part of Multicomp Pro's product line, which is highly rated by customers and comes with a 12-month limited warranty.
MULTICOMP PRO 7030087 Green LED Lamp Specifications:
- Power Dissipation: 78 mW
- Reverse Voltage: 5 V
- D.C. Forward Current: 30 mA
- Reverse Leakage Current: 100 pA
- Peak Forward Current: 100 mA
- Operating Temperature Range: -25°C to +85°C
- Storage Temperature Range: -40°C to +100°C
- Soldering Temperature (Dip): 260°C for 5 sec
- Soldering Temperature (Hand): 350°C for 3 sec
- Luminous Intensity: 50 mcd
- Forward Voltage: 2.1 - 2.6 V
- Peak Wavelength: 567 nm
- Dominant Wavelength: 572 nm
- Viewing Angle: 30 degrees
- Spectrum Line Halfwidth: 30 nm
- Material: GaP / GaP
- Lens Color: Green, Water-clear
Buy the Multicomp Pro 703-0087 – Reliable Green LED Lamp for Industrial Applications
Purchase the Multicomp Pro green LED lamp 7030087 online today for high-quality LED indicators and lighting solutions. With a 3mm size, water-clear lens, 50 millicandelas luminosity, and a 30° viewing angle, this reliable component supports your industrial and electronic projects. Made with GaP/GaP chip and housed in epoxy resin, it ensures durability and excellent optical performance. Perfect for indicator lights, displays, and illumination applications, this LED provides excellent brightness, low power consumption, and robust operation within -25°C to +85°C temperature range. Buy now and secure a dependable component for your project needs.
Order your Multicomp Series 7030087 green LED lamp today and enhance your LED lighting or indicator projects with dependable performance and quality.
