MULTICOMP PRO HC49SM4915230506016ATF Crystal Oscillator
This high-quality crystal is designed for efficient clock and timing applications in communication equipment, microcontrollers, and industrial systems. Featuring a ceramic package with ultra-thin height of 1.4mm, it offers exceptional reliability and performance. With a frequency range of 10 to 30 MHz or 30 to 60 MHz, it ensures precise tolerance of +20, +30, or +50ppm at 25°C. Suitable for space-constrained designs, it's supplied taped and reeled for ease of assembly, making it ideal for modern electronics requiring accurate oscillation frequency in compact packages.
MULTICOMP PRO HC49SM4915230506016ATF Crystal Oscillator Specifications:
- Nominal Frequency Range: 10 to 30 MHz or 30 to 60 MHz
- Vibration Mode: Fundamental (AT), 3rd Overtone (AT)
- Frequency Tolerance at 25°C: +20, +30, or +50ppm
- Temperature Stability: +30 or +50ppm
- Operating Temperature Range: -20°C to +70°C
- Storage Temperature Range: -30°C to +80°C
- Load Capacitance: 8pF to 32pF or series
- Equivalent Series Resistance: See ESR table
- Shunt Capacitance: 7pF maximum
- Drive Level: 100uW maximum
- Insulation Resistance: 500MΩ minimum at 100V DC
- Aging: +5ppm per year
Buy the Buy Multicomp Crystal Part Number HC49SM4915230506016ATF Online
Purchase the Multicomp series crystal oscillator online for reliable clock and timing functions in microcontrollers and communication devices. This ultra-thin, surface-mount component offers high precision with tolerance levels of +20, +30, or +50ppm at 25°C, making it suitable for compact, space-constrained applications. Delivered taped and reeled for easy assembly, it supports a wide temperature range from -20°C to +70°C and features low drive levels for optimal power efficiency. Trust this high-performance crystal to deliver consistent oscillation stability in your critical projects.
Order your Multicomp Series HC49SM4915230506016ATF crystal today and ensure precise timing for your electronic projects with reliable, space-saving design.
Frequently Asked Questions
Where can I buy MULTICOMP PRO HC49SM4915230506016ATF?
You can click on the BUY or RFQ button to purchase HC49SM4915230506016ATF from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part HC49SM4915230506016ATF?
You can download the HC49SM4915230506016ATF datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of HC49SM4915230506016ATF?
MULTICOMP PRO
