MULTICOMP PRO HGBJ5016 Three-Phase Bridge Rectifier
The HGBJ5016 is a glass passivated three-phase bridge rectifier designed for high reliability power electronics applications. Its features include a low forward voltage drop, insulation voltage of 2,500V, small size and lightweight design, along with low thermal resistance and high thermal conductivity, ensuring efficient heat dissipation. Suitable for power supply units, PWM converter input rectification, and DC motor drives, this rectifier performs efficiently at a maximum operating temperature of 150°C, with a peak surge current of 450A, and a typical forward voltage of 17.5V. Constructed with copper alloy and UL 94V-0 flammability rating, it is ideal for high-performance AC/DC conversion systems.
MULTICOMP PRO HGBJ5016 Three-Phase Bridge Rectifier Specifications:
- Peak Repetitive Voltage VRRM: 1,600V
- Peak Non-Repetitive Reverse Voltage VrsM: 1,700V
- Maximum Average Forward Current Iw: 50A
- Peak Forward Surge Current Irsm: 450A
- Maximum Forward Voltage Drop: 17.5V
- Reverse Peak Current Vr: 3mA at 150°C
- RMS Isolation Voltage Viso: 2,500V
- Thermal Resistance Resc: 0.8°C/W
- Operating Temperature Range: -55°C to +150°C
- Dimensions: 1.874in x 0.209in (47.6mm x 6.3mm), other dimensions in diagram
- Mounting torque: 0.8 N·m
- Weight: 10g
- Construction: Glass passivated chip, copper alloy contacts
- Package: Bridge rectifier with four diodes for three-phase conversion
Buy the Multicomp Series HGBJ 3 Phase Bridge Rectifier: HGBJ5016
Purchase the Multicomp HGBJ5016 three-phase bridge rectifier online today for exceptional reliability and high-performance AC/DC conversion. This compact, lightweight rectifier features a 2,500V insulation voltage, low forward voltage drop, and excellent thermal management. Ideal for power supplies, inverter circuits, PWM converters, and motor drives, it ensures efficient heat dissipation with high thermal conductivity. With a maximum operating temperature of 150°C and surge current capability of 450A, this rectifier offers durability and reliability for demanding industrial applications. Buy now to enhance your power systems!
Get Multicomp HGBJ5016 today—built for high reliability in power conversion systems and efficient heat dissipation.
