MULTICOMP PRO MBR16100CT Power Rectifier
The MBR16100CT is a high-performance Schottky barrier power rectifier designed for low voltage, high frequency rectification, and polarity protection applications. It features epitaxial construction with oxide passivation and metal overlay contact, ensuring low forward voltage, low switching noise, high current capacity of 16 Amperes, and a maximum reverse voltage of 100 Volts. Its robust design includes a guard-ring for stress protection, guaranteeing reverse avalanche, and operates reliably up to 150°C junction temperature. Ideal for efficient, high-speed rectification in compact circuits.
MULTICOMP PRO MBR16100CT Power Rectifier Specifications:
- Maximum Repetitive Reverse Voltage: 100 V
- Working Peak Reverse Voltage: 100 V
- RMS Reverse Voltage: 70 V
- Average Rectifier Forward Current: 8.0 A per diode, Total Device 16 A
- Peak Repetitive Forward Current: 16 A
- Non-Repetitive Peak Surge Current: 450 A
- Junction Temperature Range: -65°C to +150°C
- Maximum Forward Voltage at 8A: 0.85 V (25°C), 0.73 V (100°C)
- Thermal Resistance Junction to Case: 3.8°C/W
- Maximum Reverse Current at 25°C: 0.2 mA, at 125°C: 20 mA
- Dimensions (millimeters): A 15.32–16.48, B 9.78–10.42, C 50–65, D 13.06–14.62, E 3.57–4.07, F 2.42–2.66, G 1.12–1.36, H 0.72–0.96, I 4.22–4.98, J 114–138, K 2.20–2.98, L 0.33–0.55, M 248–298, O 370–3.90
- Operating temperature range: -65°C to +150°C
Buy the Multicomp Pro Series Power Rectifier: MBR16100CT
Purchase the Multicomp Pro Series power rectifier MBR16100CT online today and enjoy high current capacity up to 16A with a voltage rating of 100V. Its low forward voltage ensures minimal power loss, making it ideal for high-frequency rectification, switch-mode power supplies, and polarity protection. Designed with epitaxial construction and oxide passivation, it offers low switching noise, robust avalanche capability, and operation up to 150°C. Ensure your electronic projects are efficient and reliable by ordering this durable, high-quality Schottky barrier rectifier now.
Order your Multicomp Pro Series MBR16100CT high current rectifier today and ensure your power circuits operate with optimal efficiency and reliability.
