MULTICOMP-PRO MC000050 PCB Terminal Block
The MC000050 is a 2-way, 30A wire-to-board terminal block featuring a tin-plated brass terminal, a green polyamide 66 insulating body, a nickel-plated brass cage clamp, and a steel nickel-plated screw. It provides screw wire connections with a through-hole, right-angle orientation. The terminal block offers an insulation resistance of over 2000MΩ at 500VDC and operates within a temperature range of -40°C to 105°C. It is part of the Multicomp Pro product lineup, rated highly by users, with a 12-month limited warranty.
MULTICOMP-PRO MC000050 PCB Terminal Block Specifications:
- Current rating: 30 amperes, 300 V ac
- Minimum insulation withstand voltage: 2,000 V ac
- Insulation resistance: > 2,000 MΩ at 500 V dc
- Operating temperature: -40°C to +105°C
- Wire strip length: 8 mm
- Wire range: 20 to 12 AWG
- Screw torque: 5.5 lb-inch
- Pitch: 6.35 mm (0.25 inch)
- Material: Insulating Body—Polyamide 66 in green
- Cage Clamp: Nickel-plated brass
- Terminal: Tin plated
- Screw: Steel, nickel-plated
- Number of Poles: 2
- Dimensions (A): 12.7 mm (0.5 inch)
Buy the MultiComp Series PCB Terminal Block: MC000050
Order the MultiComp PCB Terminal Block MC000050 online now for efficient and secure wire-to-board electrical connections. Designed for quick installation, it features a polyamide insulating body, brass terminals with tin plating, and nickel-plated steel screws to ensure long-term durability and high insulation resistance. Ideal for industrial automation, control panels, and electrical wiring projects, this 2-way terminal block supports wire ranges from 20 to 12 AWG and operates within a temperature range of -40°C to 105°C. Enjoy fast shipping and quality assurance when you buy online.
Get MultiComp MC000050 today—built for reliable electrical connections and industrial durability.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MC000050?
You can click on the BUY or RFQ button to purchase MC000050 from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MC000050?
You can download the MC000050 datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MC000050?
MULTICOMP-PRO
