MULTICOMP PRO MC000106 Right-Angle Terminal Block
The MC000106 is a 4-way, 10A right-angle pluggable terminal block with a green polyamide 66 insulating body. It features tin-plated phosphor bronze contacts and a nickel-plated steel screw, providing screw wire connection. The terminal block offers a minimum insulation withstand voltage of 2000VAC and an insulation resistance exceeding 2000 megaohms at 500V. It operates within a temperature range of -40°C to 105°C. Suitable for industrial control panels and wiring applications, this terminal block ensures reliable electrical connections in challenging environments.
MULTICOMP PRO MC000106 Right-Angle Terminal Block Specifications:
- Current rating: 10 amperes, 300 V ac
- Minimum insulation withstand voltage: 2,000 V ac
- Insulation resistance: > 2,000 Megaohms at 500 V de
- Operating temperature: -40°C to +105°C
- Wire strip length: 6.5 mm
- Wire range: 16 to 24 AWG
- Screw torque: 3 Ib-inch
- Material: Polyamide 66 - Green
- Contact material: Phosphor Bronze, Tin plated
- Screw material: Steel, Nickel plated
- Dimensions: Pitch: 3.81 mm (0.15 inch)
- Poles: 4
- Part Number: MC000106
Buy the Multicom U0026 Pro 4-way 10A Right-Angle Plug Terminal Block for Industrial Applications
Enhance your wiring setup with this high-quality 4-way, 10A right-angle terminal block featuring a durable polyamide body, tin-plated contacts, and steel screw connections. Designed for industrial environments, it withstands voltages up to 2000VAC and temperatures from -40°C to 105°C. Its 6.5 mm wire strip length and compatibility with 16 to 24 AWG wires ensure versatile usage. Trust this reliable terminal connection solution for safe, efficient, and long-lasting electrical installations in control panels, machinery, and automation systems.
Buy Multicom U0026 Pro 4-way 10A right-angle plug terminal block now and ensure reliable, safe electrical connections in your industrial projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC000106?
You can click on the BUY or RFQ button to purchase MC000106 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC000106?
You can download the MC000106 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC000106?
MULTICOMP PRO
