MULTICOMP-PRO MC001503 RPSMA Bulkhead Connector
The IP67 RPSMA Bulkhead Jack - UFL is a high-performance RF connector designed for reliable, weatherproof connections in challenging environments. Operating over DC to 6 GHz frequency range, it offers low insertion loss of -1.4 dB and maximum VSWR of 1.65:1. Constructed with durable halogen-free shell and sealed for IP67 water and dust resistance, it is ideal for outdoor and industrial applications. The connector supports a maximum working voltage of 60 Vrms, dielectric withstand voltage of 200 Vrms, and insulator resistance of 500 MΩ, ensuring excellent electrical performance.
MULTICOMP-PRO MC001503 RPSMA Bulkhead Connector Specifications:
- Impedance: 50Ω
- Frequency Range: DC to 6 GHz
- Working Voltage: 60 Vrms Max.
- Dielectric Withstanding Voltage: 200 Vrms Max.
- Insulator Resistance: 500 MΩ Min.
- Insertion Loss: -1.4 dB Max.
- VSWR: 1.65:1 Max.
- Seal: IP67 rated for water and dust ingress protection
- Connector Type: RPSMA Bulkhead Jack with UFL connection
- Cable Compatibility: 1.37 mm diameter, blue cable
- Shell Material: Halogen-free
- Dimensions: Not specified but designed for secure mounting with standard hole requirements
- Maximum Frequency: 6 GHz
- Application: Outdoor, industrial RF connections
- RoHS Compliant
Buy the Buy Multicomp IP67 RPSMA Bulkhead Jack Part Number MC001503 Online
Discover the durable and waterproof RPSMA bulkhead connector designed specifically for outdoor and industrial RF applications. With IP67 sealing, low insertion loss of -1.4 dB, and operation from DC to 6 GHz, this connector ensures high performance and reliable connections even in harsh environments. Constructed with halogen-free materials, it supports maximum working voltage of 60 Vrms and dielectric withstand voltage of 200 Vrms. Buy online today to experience secure, weatherproof connections that meet demanding industrial standards.
Order your Multicomp Series MC001503 IP67 RPSMA Bulkhead Jack today and secure reliable, waterproof RF connections for outdoor and industrial projects.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MC001503?
You can click on the BUY or RFQ button to purchase MC001503 from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MC001503?
You can download the MC001503 datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MC001503?
MULTICOMP-PRO
