MULTICOMP PRO MC001832 Dual-Pole Terminal Block
The MC001832 from Multicomp Pro is a high-quality dual-row terminal block with a 12mm pitch and 3 poles, suitable for wire sizes from 10 AWG to 22 AWG. It supports a current of 41A and a voltage of 450V, making it ideal for industrial electrical connections. Operating within a temperature range of -40°C to +85°C, it features a robust design with insulation withstand voltage of at least 2000VAC, and insulation resistance exceeding 2000 MΩ at 500VDC. The terminal utilizes white PA66 (UL94-V2) insulation, zinc-plated steel screws, and brass cage clamps with nickel plating for durability and reliability in demanding environments.
MULTICOMP PRO MC001832 Dual-Pole Terminal Block Specifications:
- Current Rating: 41A
- Insulation Withstands Voltage: AC2000V min
- Insulation Resistance: >2,000 MΩ at 500VDC
- Operation Temperature: -40°C to +85°C
- Wire Range: 10 AWG to 22 AWG
- Screw Torque: 7 Lb-inch (0.8Nm)
- Stripped Length: 5.5mm to 6.5mm
- Material: Insulating Body PA66 (UL94-V2)
- Screws: Steel Zinc Plated
- Cage Clamp: Brass Nickel Plated
- Dimensions: 31.6mm length, 24mm width, pole spacing 12mm
Buy the Multicomp Dual-Pole Terminal Block – Reliable Industrial Connection for Industrial Applications
Purchase the Multicomp Pro dual-pole terminal block online today to ensure secure electrical connections in industrial environments. Designed with a 12mm pitch and robust construction, it supports wire sizes from 10 to 22 AWG, with a current rating of 41A and voltage of 450V. Suitable for applications requiring high insulation resistance and operation within -40°C to +85°C. Featuring zinc-plated steel screws, brass cage clamps, and UL94-V2 insulation, this terminal block offers durability, reliability, and ease of use for industrial wiring challenges.
Get Multicomp Pro MC001832 today—built for precision with high current capacity and long-lasting durability in industrial wiring systems.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC001832?
You can click on the BUY or RFQ button to purchase MC001832 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC001832?
You can download the MC001832 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC001832?
MULTICOMP PRO
