MULTICOMP PRO MC002333 Solid State Relay
This panel mount solid state relay provides reliable single phase AC switching with a load current range from 10A to 125A, suitable for resistive, inductive, or capacitive loads. It features zero crossing or random-on operation, a dielectric strength of 24,000V, and is RoHS compliant. The relay supports control voltages from 4-32V DC and 90-280V AC, with load voltages up to 600V AC. Ideal for industrial automation, HVAC, food processing machinery, and various high-temperature applications, ensuring efficient and safe electrical performance.
MULTICOMP PRO MC002333 Solid State Relay Specifications:
- Load Current: 10A ~ 125A @ 48 ~ 660V AC
- Load Voltage Range: 240V AC, 480V AC, 600V AC
- Control Voltage Range: 4-32V DC, 90-280V AC
- Dielectric Strength: 24,000V ACrms
- Maximum Off-state Leakage Current: 5mA at Rated Voltage
- Maximum Surge Current (10ms): 1250A
- Temperature Operating Range: -30°C to +80°C
- Weight: 96g (Standard), optional High Profile 180g
- RoHS Compliant
- Build-in MOV or TVS option available
- Support for Zero Crossing or Random-on switching
- Reliable switching for resistive, inductive, and capacitive loads
- Suitable for high-temperature chambers, machinery, HVAC, lighting, and automation systems
- Physical Dimensions: Output max W=12mm, Input max W=9.5mm
Buy the Multicomp Pro MC002333 – Reliable Solid State Relay for Industrial Applications
Order the Multicomp Pro solid state relay MC002333 online today and boost your industrial automation setup. Designed for single phase AC switching, it handles loads up to 125A with zero crossing or random-on operation. Its wide control voltage range and high dielectric strength ensure safety and efficiency. Perfect for HVAC, machinery, and high-temperature chambers, this relay guarantees reliable operation, quick response times, and durable performance in demanding industrial environments. Don’t miss your chance to enhance your system’s reliability with a trusted relay product.
Buy Multicomp Pro MC002333 now and experience unmatched reliability and performance in high-current switching environments.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC002333?
You can click on the BUY or RFQ button to purchase MC002333 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC002333?
You can download the MC002333 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC002333?
MULTICOMP PRO
