MULTICOMP PRO MC0125W120611K2 Thick Film Resistor Series
The Multicomp Pro MC series thick film chip resistors provide resistance values from 1 ohm to 10 megaohms, with E96 and E24 values. Available in sizes 0402, 0603, 0805, and 1206, they are ideal for small, lightweight designs. Suitable for wave and reflow soldering, they help reduce assembly costs. Max voltages are 50V for smaller sizes and up to 200V for 1206. Tolerance options include ±1%, ±2%, and ±5%, with power ratings of 62.5mW to 125mW. Temperature Coefficient (TCR) varies from ±400ppm/°C to ±100ppm/°C across resistance ranges, operating from -55°C to +155°C.
MULTICOMP PRO MC0125W120611K2 Thick Film Resistor Series Specifications:
- Resistance range: 1Ω to 10MΩ, including E24 and E96 series
- Sizes: 0402, 0603, 0805, 1206
- Maximum working voltages: 50V (0402, 0603), 150V (0805), 200V (1206)
- Tolerance options: ±1%, ±2%, ±5%
- Power ratings: 62.5mW, 100mW, 125mW
- Temperature Coefficient of Resistance: ±400ppm/°C (1-10Ω), ±200ppm/°C (11-100Ω), ±100ppm/°C (higher values)
- Operating temperature range: -55°C to +155°C
- Suitable for wave and reflow soldering, aiding in cost reduction
- Jumpers available for all sizes
Buy the Multicomp Series Thick Film Resistors: MC0125W120611K2
Order the Multicomp MC1206 series thick film resistors online today for reliable performance across a wide resistance range from 1 ohm to 10 megaohms. Designed for small, lightweight electronic designs, these resistors are compatible with wave and reflow soldering, which helps reduce assembly costs. They feature various tolerance options including ±1%, ±2%, and ±5%, and operate safely within temperatures from -55°C to +155°C. Choose from sizes 0402, 0603, 0805, and 1206 with voltage ratings up to 200V and power ratings up to 125mW, ensuring versatility and robust performance in your projects.
Get Multicomp thick film resistor 1206 size MC0125W120611K2 today—built for precision and long-lasting durability.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC0125W120611K2?
You can click on the BUY or RFQ button to purchase MC0125W120611K2 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC0125W120611K2?
You can download the MC0125W120611K2 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC0125W120611K2?
MULTICOMP PRO
