MULTICOMP PRO MC254100000IDC Flat Cable IDC Socket
This high-quality 2.54mm flat cable IDC socket from Multicomp Pro features a 12-position design suitable for reliable connections in electronic projects and PCB assemblies. Made from UL94V-0 rated PBT insulator and copper alloy contacts, it provides excellent durability and electrical performance. Rated for 30V AC/DC and 1A current, it withstands voltages up to 500V for one minute. Operating efficiently between -40°C to +105°C, the socket offers a gold-plated finish for enhanced contact reliability, making it ideal for various industrial and consumer electronic applications.
MULTICOMP PRO MC254100000IDC Flat Cable IDC Socket Specifications:
- Current Rating: 1A
- Voltage Rating: 30V AC/DC
- Contact Resistance: 20mΩ Max.
- Insulation Resistance: 1000MΩ Min.
- Withstanding Voltage: 500V AC for one minute
- Operating Temperature Range: -40°C to +105°C
- Materials and Finish: PBT (UL94V-0), Copper Alloy, Selective Gold Plated
- Physical Dimensions: Length varies with number of positions, for 12POS it is approximately 19.92mm x 12.7mm
- Color: Black
- RoHS Compliance: Yes
Buy the Buy Multicomp Pro 2.54mm Flat Cable IDC Socket Part Number MC254100000IDC Online
Secure your electronic projects with the reliable 2.54mm flat cable IDC socket by Multicomp Pro. Crafted with high-quality materials including UL94V-0 rated PBT and gold-plated contacts, it ensures a durable connection for industrial, automation, and hobbyist applications. Rated at 30V AC/DC and 1A, with a withstand voltage of 500V for one minute, it operates reliably between -40°C and +105°C. Easy to install, it features a 12-position design ideal for PCB wiring and harness assemblies.
Buy Multicomp Pro MC254100000IDC now and experience unmatched reliability and performance in your electronic connections.
