MULTICOMP PRO MC2541400STSMD Vertical SMD Box Header
This high-quality 2.54mm box header boasts a double row, vertical SMD design suitable for compact electronic assemblies. Made from high-temp nylon UL94V-0 insulator, it features gold-plated copper alloy contacts rated for 600V AC/DC, withstanding temperatures from -40°C to +105°C. The header ensures reliable connections with 22mΩ contact resistance and 1000MΩ insulation resistance. It supports IR reflow at 260°C for 5 seconds maximum, making it ideal for durable, space-efficient circuit connections in various industrial and consumer electronics applications.
MULTICOMP PRO MC2541400STSMD Vertical SMD Box Header Specifications:
- Current Rating: 22mΩ contact resistance
- Voltage Rating: 600V AC/DC for one minute
- Insulation Resistance: 1000MΩ minimum
- Contact Resistance: 22mΩ
- Materials: Copper Alloy contacts, High Temp Plastic (Nylon 6T UL94V-0) insulator, Gold Plated contacts
- Operating Temperature Range: -40°C to +105°C
- IR Reflow Temperature: 260°C, 5 Sec. Max.
- Dimensions vary depending on pin count, ranging from approximately 15.28mm x 5.08mm to 50.84mm x 40.64mm for different models
- RoHS Compliant, rated for 250V AC/DC, with UL94V-0 flammability rated plastic
Buy the Multicomp Series Box Header: 2.54mm 6POS: MC25406
Order the vertical 2.54mm box header online today to ensure your electronics assembly benefits from high durability, excellent conductivity, and space-efficient design. These headers feature gold-plated contacts for enhanced corrosion resistance, rated for 600V AC/DC, and operate reliably within -40°C to +105°C temperature range. Suitable for high-temperature reflow processes, the headers support various pin configurations from 6 to 34 positions. Easy to install, RoHS compliant, and perfect for industrial, consumer, and automation electronics requiring secure, compact, and durable connections.
Buy Multicomp 2.54mm box header now and experience reliable, space-saving connections for your electronic projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC2541400STSMD?
You can click on the BUY or RFQ button to purchase MC2541400STSMD from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC2541400STSMD?
You can download the MC2541400STSMD datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC2541400STSMD?
MULTICOMP PRO
