MULTICOMP PRO MC33165 PPTC Resettable Fuse
The Multicomp Pro PPTC resettable fuse offers robust overcurrent protection for electronic circuits, featuring a rated voltage of 30V and operating currents from 900mA to 9A. Designed with tin-plated copper leads complying with RoHS standards, it withstands a temperature range of -40°C to 85°C. Its flame-retardant epoxy insulating coating ensures safety and durability during soldering per MIL-STD-202. Available in various dimensions with lead sizes of 20 or 24 AWG, it provides reliable performance in industrial and consumer electronics applications. The fuse's rapid trip feature protects circuits efficiently from short circuits or overloads.
MULTICOMP PRO MC33165 PPTC Resettable Fuse Specifications:
- Lead Material: Tin Plated Copper
- RoHS Compliant
- Soldering Characteristic: MIL-STD-202, Method 208E
- Insulating Coating: Flame Retardant Epoxy
- Operating Current: 900mA to 9A
- Maximum Voltage: 30V
- Temperature Range: -40°C to 85°C
- Lead Size: 20 or 24 AWG
- Lead Diameter: 0.51mm (24 AWG), 0.81mm (20 AWG)
- Dimensions vary by model, typically ranging from 5.1mm to 24.9mm in length, with typical diameters of 3mm
- Rated Current and Voltage are specified per model for circuit protection
Buy the Multicomp PPTC – Reliable Resettable Fuse for Industrial Applications
Secure your circuits with the reliable Multicomp Pro PPTC resettable fuse, rated for 30V and currents from 900mA to 9A. This fuse features RoHS-compliant tin-plated copper leads, flame-retardant epoxy coating, and complies with MIL-STD-202 soldering standards, providing excellent durability. Its wide operating temperature range of -40°C to 85°C makes it suitable for diverse environments. Whether for industrial or consumer electronics, this fuse offers rapid response to overloads, protecting sensitive components efficiently. Purchase online now for quick, reliable circuit protection.
Order your Multicomp Pro Series MC33165 resettable fuse today and ensure robust circuit protection in your industrial projects with dependable performance.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC33165?
You can click on the BUY or RFQ button to purchase MC33165 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC33165?
You can download the MC33165 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC33165?
MULTICOMP PRO
