MULTICOMP PRO MC34659 Vertical Header Connector
The MC34659 is a 4-position, 2-row vertical header made with tin-plated brass contacts and a transparent nylon 66 insulator. It supports a current rating of 9A AC/DC and a voltage rating of 600V AC/DC. The connector features a contact resistance of less than 10 milliohms and an insulation resistance of at least 1000 megaohms. Designed for industrial use, it withstands voltages up to 1500V AC for a minute, operates from -40°C to +105°C, and complies with RoHS standards. It is ideal for PCB assembly requiring reliable electrical connections.
MULTICOMP PRO MC34659 Vertical Header Connector Specifications:
- Current Rating: 9A AC/DC
- Voltage Rating: 600V AC/DC
- Contact Resistance: > 10mΩ Max
- Insulation Resistance: 1,000MΩ Min
- Withstanding Voltage: 1,500V AC for One Minute
- Operating Temperature: -40°C to +105°C
- Material: Insulator - Nylon 66, Contact - Brass, Plating - Tin
- Dimensions: DimA 9.6 mm, DimB 4.2 mm
- Number of Circuits: 4
- RoHS Compliant
Buy the Buy Multicomp Pro Header Vertical Part Number MC34659 Online
Enhance your PCB assemblies with the dependable Multicomp Pro vertical header. Featuring four circuits, tin-plated brass contacts, and a transparent nylon insulator, MC34659 offers excellent electrical performance rated for 9A and 600V. Withstanding up to 1500V AC for a minute and operating from -40°C to +105°C, it is perfect for industrial and commercial applications. Buy online today for quick delivery and reliable quality with a 12-month warranty. Trust this connector for durable, high-performance connections in your projects.
Order your Multicomp Pro MC34659 vertical header today and ensure reliable electrical connections with high-quality industrial-grade connectors.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC34659?
You can click on the BUY or RFQ button to purchase MC34659 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC34659?
You can download the MC34659 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC34659?
MULTICOMP PRO
