MULTICOMP PRO MCDTS24N Surface Mount Tactile Switch
The MCDTS2-4N from Multicomp Pro is an ultra-miniature surface mount tactile switch designed for high-density applications. It features a single-pole single-throw normally open (SPST-NO) configuration with a contact rating of 50mA at 12V DC. Operating reliably from -25°C to +70°C, it provides a distinct tactile click and positive feedback. Made with stainless steel and nylon thermoplastic, it ensures high durability suitable for industrial, automation, and power management uses. The switch’s compact size and reliable performance make it ideal for compact electronic assemblies and high-density mounting scenarios.
MULTICOMP PRO MCDTS24N Surface Mount Tactile Switch Specifications:
- Operation Force: 160 +50 gf (Brown), 260 +50 gf (Red), 100 +50 gf (Black)
- Stop Strength: Place the switch with a 3 kgf static load for 15 seconds
- Stroke: 0.35 ± 0.1mm (12 * 12) 0.25 +0.2/-0.1mm (6 * 6)
- Operating Temperature: -25°C to +70°C
- Storage Temperature: -30°C to +80°C
- Vibration Test: MIL-STD-202F method 201 A, 10-55-10 Hz/1 minute, 2 hours each direction
- Shock Test: MIL-STD-202F method 213 B, 50 G (peak), 11 msec, 6 sides with 3 cycles
- Electrical Life: 50,000 cycles at 260 gf, 500,000 cycles at 100 gf, 160 gf
- Current Rating: 50mA at 12V DC
- Max Contact Resistance: 100mΩ
- Insulation Resistance: 10 MΩ at 500V DC
- Dielectric Strength: 250V AC/1 minute
- Max Wave Solder Temperature: 260°C for 5 seconds
- Hand Soldering Temperature: 320°C for 2 seconds
- PCB Hole Diameter: 1.6 mm
- Material: Cover: Stainless Steel, Base: Nylon thermoplastic, Contact disc: Phosphor bronze with silver cladding
- Dimensions: 12mm x 12mm, height varies with actuator
- RoHS Compliant
- Soldering Process: Wave at 500°F (260°C) max. for 5 seconds; Hand soldering using 30W soldering iron at 608°F (320°C) for 2 seconds
Buy the Multicomp Series Tactile Switch: MCDTS24N
Order the Multicomp Series MCDTS24N tactile switch online today and enhance your electronic projects with this compact, reliable, and high-performance component. Designed for high-density mounting, it offers positive tactile feedback and consistent operation across a wide temperature range. Its durable construction with stainless steel and nylon thermoplastic ensures longevity, making it ideal for automation, industrial control, and power management systems. With quick SMD soldering options and RoHS compliance, this switch guarantees ease of assembly and environmental safety. Purchase now for dependable performance in your manufacturing and prototyping needs.
Buy Multicomp Series MCDTS24N now and experience unmatched reliability and high-density performance for your electronic applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCDTS24N?
You can click on the BUY or RFQ button to purchase MCDTS24N from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCDTS24N?
You can download the MCDTS24N datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCDTS24N?
MULTICOMP PRO
