MULTICOMP PRO MCFE01512 Toroidal Power Transformer
This toroidal transformer provides reliable power conversion with a 15VA rating, featuring dual 12V secondary winding outputs. Designed with RoHS compliance, it offers efficient operation with typical efficiency of 83% and low iron and copper losses. The transformer has a compact outer diameter of 62.4mm and height of 34.5mm, weighing 0.36kg. It operates at input voltages of 230V with a frequency of 50/60Hz, suitable for industrial, automation, and control applications. The device's insulation system includes Class B and Class H wiring, meeting safety standards. Durable leads rated at 600V / 105°C ensure secure connections, with primary leads double insulated and made from UL1015 rated cable.
MULTICOMP PRO MCFE01512 Toroidal Power Transformer Specifications:
- Input Voltage: 230V 50/60Hz
- Rated Power: 15VA
- Secondary Voltage: 12V x 2
- Secondary Resistance: 2.26 Ohms per 20°C at 12V
- Magnetising Current: 2.5mA approx
- Iron Loss: 0.237 Watts approx
- Copper Loss: 2.75 Watts approx
- Efficiency: 83% typical
- Temperature Rise: 33°C approx
- Ambient Temperature Rating: 240°C
- Winding Wire: Class H (180°C)
- Insulation System: Class B (130°C)
- Leadout Insulation: Class A (105°C)
- Outer Diameter: 62.4mm
- Height: 34.5mm
- Weight: 0.36kg
- Lead Lengths: approximately 5mm, tinned ends
- Cable Rating: UL1015, 600V / 105°C, VW-1
- Primary Leads: Double insulated with PVC sleeving
- Termination: All leads tinned to 6mm
Buy the Multicomp Toroidal – Reliable 15VA Power Transformer for Industrial Applications
Purchase the reliable Multicomp Toroidal 15VA power transformer online today. This high-quality, RoHS compliant transformer offers dual 12V outputs with excellent efficiency, low losses, and durable UL-rated leads. Its compact design fits various industrial and control applications, providing stable performance and safety with Class B insulation and double-insulated primary leads. Buy now to upgrade your electrical systems with a dependable power conversion solution that guarantees safety, durability, and efficiency for your projects.
Order your Multicomp Toroidal 15VA transformer today and ensure dependable power supply for your industrial or control projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCFE01512?
You can click on the BUY or RFQ button to purchase MCFE01512 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCFE01512?
You can download the MCFE01512 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCFE01512?
MULTICOMP PRO
