MULTICOMP PRO MCFE03006 Toroidal Transformer
This toroidal multicomponent transformer provides reliable AC power conversion with a 15VA rating, featuring dual secondary outputs of 6V, 9V, 12V, 15V, 18V, or 25V. Its compact design includes RoHS compliance, robust insulation systems, and UL-rated terminal leads, ensuring safety and durability in various electronic and industrial applications. With an efficiency of approximately 86% and low iron and copper losses, it operates with a temperature rise of 34°C and is suitable for ambient temperatures up to 240°C. Ideal for use in control panels, automation systems, and power supplies.
MULTICOMP PRO MCFE03006 Toroidal Transformer Specifications:
- Input Voltage: 230V, 50/60Hz
- DC Resistance: 87Ω ±15% @ 20°C
- Magnetising Current: 4mA approx. at 230V 50Hz
- Iron Loss: 0.39 Watts approx.
- Copper Loss: 4.3 Watts approx.
- Efficiency: 86% typical
- Temperature Rise: 34°C approx.
- Ambient Temperature Rating: 240°C
- Winding Wire Class: H (180°C)
- Insulation System Class: B (130°C)
- Leadout Insulation: Class A (105°C)
- Overall Insulation Class: A (105°C)
- Outer Diameter: 81.3mm
- Height: 39mm
- Weight: 0.62kg
- Lead Length: Approximately 150mm, tin-plated, double insulated, rated 600V/105°C
- Termination: All leads rated UL1015, VW-1, with PVC sleeving
- Secondary Voltages: 6V, 9V, 12V, 15V, 18V, 25V with respective resistances and gauge sizes
- Dimensions of parts: Outer Diameter 81.3mm, height 39mm, weight 0.62kg
Buy the Buy Multicomponent Toroidal Transformer Part Number MCFE03006 Online
Purchase the reliable and efficient Multicomponent Toroidal Transformer MCFE03006 online today. Designed with dual secondary outputs of 6V to 25V, it offers high efficiency and robust insulation for industrial, automation, and control applications. Its compact size combined with UL-rated leads ensures safety and convenience. Ideal for power supplies, control panels, and electronic device integration, this transformer provides consistent performance with low iron and copper losses, making it a valuable addition to any professional or DIY electronics setup.
Get Multicomponent MCFE03006 today—built for precise voltage regulation and long-lasting durability in your electronic projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCFE03006?
You can click on the BUY or RFQ button to purchase MCFE03006 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCFE03006?
You can download the MCFE03006 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCFE03006?
MULTICOMP PRO
