MULTICOMP PRO MCHP05W4F2201T5E High Power Thick Film Resistor
The Multicomp Pro HP05 series are surface-mount, high-power thick film resistors featuring resistance values from 1 ohm to 10 megohms. Designed for both wave and reflow soldering, these 0805 size resistors offer tolerances of ±1% or ±5%. Each resistor has a power rating of 250mW, maximum working voltage of 150V, and a temperature coefficient of ±200 ppm/°C for low resistance and ±100 ppm/°C for higher values. They are suited for industrial, electronic, automation, and control applications requiring reliable, high-power performance in a compact package.
MULTICOMP PRO MCHP05W4F2201T5E High Power Thick Film Resistor Specifications:
- Resistance range: 1Ω to 10MΩ
- Power rating: 0.25W
- Maximum working voltage: 150V
- Tolerance: ±1% or ±5%
- Temperature coefficient: ±200 ppm/°C for 1Ω-10Ω, ±100 ppm/°C for 11Ω-10MΩ
- Dimensions: 0805 chip size, length approximately 2.0 mm, width approximately 1.25 mm
- Suitable for wave and reflow soldering
- Operating temperature: -55°C to +155°C
- RoHS compliant
- Inner termination: Silver
- Outer termination: Tin-plated
- Material: High purity alumina substrate with resistive film
- Marking: Resistance value indicated by three or four digit code
- Reliability: Designed for high-power applications in electronic circuits
- Application: AV adapters, LCD backlights, camera strobe, industrial and automation controls
Buy the Multicomp Series HP05 High Power Thick Film Resistor: MCHP05W4F2201T5E
Purchase your Multicomp Series HP05 high-power thick film resistor online today and enhance your electronic projects with dependable, high-quality components. These surface-mount resistors in 0805 size deliver power ratings of 250mW, resistance from 1 ohm to 10 megohms, and operate at voltages up to 150V. Engineered for both wave and reflow soldering, they provide excellent thermal stability with a temperature coefficient of ±200 ppm/°C. Ideal for industrial equipment, control systems, and high-performance circuits, avail yourself of fast online ordering and worldwide delivery.
Order your Multicomp Series HP05 high-power thick film resistor today and ensure your electronic projects benefit from reliable performance in a compact 0805 package.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCHP05W4F2201T5E?
You can click on the BUY or RFQ button to purchase MCHP05W4F2201T5E from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCHP05W4F2201T5E?
You can download the MCHP05W4F2201T5E datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCHP05W4F2201T5E?
MULTICOMP PRO
