MULTICOMP-PRO MCHVS1D06G Pin Header Connector
This dual-row, vertical surface-mount pin header with cap offers reliable electrical contact and easy assembly for compact electronic modules. Constructed with high-temperature plastic insulators and gold-plated copper alloy contacts, it provides excellent corrosion resistance and durability. Designed for 1mm pitch with a height of 3.7mm, it accommodates multiple pin counts from 6 to 40 positions, ensuring versatile connections in various PCB applications. Its RoHS compliance and robust specifications make it suitable for demanding industrial, automation, and electronic device projects.
MULTICOMP-PRO MCHVS1D06G Pin Header Connector Specifications:
- Current Rating: 1A AC/DC
- Voltage Rating: 50V AC/DC
- Contact Resistance: 20mΩ Max
- Insulation Resistance: 1000MΩ Min
- Withstanding Voltage: 500V for one minute
- Operating Temperature Range: -25°C to +105°C
- Material: High-temperature plastic (LCP UL94V-0)
- Contact Material: Copper Alloy, Gold Plated
- Dimensions: Pitch 1mm, Height 3.7mm, varies with pin count
- Number of Positions: 6, 8, 10, 12, 14, 20, 30, 40
- Construction: Double row, vertical, SMD type
- RoHS Compliant
Buy the MultiComp Series Pin Header: MCHVS1D06G
Enhance your electronic projects with this high-quality vertical pin header with cap, featuring 1mm pitch, gold-plated contacts, and reliable SMD design. Suitable for automation, industrial machinery, and electronic devices, it offers robust performance and compliance with RoHS standards. With multiple pin configurations ranging from 6 to 40, this connector ensures flexible connection solutions. Easy to mount on PCB, it guarantees stable electrical contact and long-lasting durability, making it ideal for professional and hobbyist electronics alike. Order online today for quick delivery.
Get MultiComp Series MCHVS1D06G pin header today—built for precision, durability, and easy SMT assembly.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MCHVS1D06G?
You can click on the BUY or RFQ button to purchase MCHVS1D06G from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MCHVS1D06G?
You can download the MCHVS1D06G datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MCHVS1D06G?
MULTICOMP-PRO
