MULTICOMP-PRO MCHVS1S05G Pin Header
This 1.27mm pitch pin header with cap is a single-row, vertical, SMD type connector designed for reliable interconnections in industrial and electronic applications. It features a high-temp plastic insulator, gold-plated copper alloy contacts, and supports currents up to 1A and voltages up to 50V. Suitable for PCB mounting, it offers excellent insulation resistance and withstands 500V for one minute, operating efficiently within -25°C to +105°C. Ideal for compact, durable connections in automation, control panels, and device assemblies.
MULTICOMP-PRO MCHVS1S05G Pin Header Specifications:
- Current Rating: 1A AC/DC
- Voltage Rating: 50V AC/DC
- Contact Resistance: 20mΩ Max.
- Insulation Resistance: 1000MΩ Min.
- Withstanding Voltage: 500V for one minute
- Operating Temperature Range: -25°C to +105°C
- Insulator Material: High temp. Plastic (Nylon 9T UL94V-0)
- Color: Black
- Contact Material: Copper Alloy
- Plating: Gold Plated
- Pin Pitch: 1.27mm
- Number of Positions: 3 to 10 positions (varies by model)
- Height: 5.1mm
- Mounting Type: SMD (Surface Mount Device)
Buy the Buy Multicomp 1.27mm Pin Header SMD Component Part Number MCHVS1S05G Online
Purchase the reliable 1.27mm pitch pin header with cap from Multicomp online today. Designed for durability and performance, it features gold-plated contacts, high-temp plastic insulation, and supports up to 1A current at 50V. This surface-mount component operates efficiently from -25°C to +105°C and withstands 500V for one minute. Ideal for PCB connections in automation, control panels, and electronic assemblies, ensuring high-quality, space-efficient, and durable connections for professional applications.
Order your Multicomp Series MC-HVS1-S05-G 1.27mm Vertical SMD Pin Header today and ensure robust, compact connections in your electronic projects.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MCHVS1S05G?
You can click on the BUY or RFQ button to purchase MCHVS1S05G from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MCHVS1S05G?
You can download the MCHVS1S05G datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MCHVS1S05G?
MULTICOMP-PRO
