MULTICOMP-PRO MCRC15KKFT00B Rocker Switch
This non-illuminated round rocker switch offers reliable switching with a durable polyamide housing and silver alloy contacts. It features a momentary rocker position, quick connect terminals, and operates efficiently within temperatures ranging from -20°C to +85°C on the terminal side. With UL and VDE safety approvals, it supports a rated electrical current of 10A at 250V AC and 15A at 125V AC. Ideal for control panels, automation, and industrial applications, this switch ensures long-lasting performance with an electrical life of 10,000 cycles and excellent resistance to humidity and temperature extremes.
MULTICOMP-PRO MCRC15KKFT00B Rocker Switch Specifications:
- Housing: Polyamide 6.6, Black
- Rocker: Polyamide 6.6 & Polycarbonate, Black
- Contacts: Silver Alloy
- Terminal: Copper or Brass, Silver Plated
- Actuator: Non-illuminated, Round
- Terminal Type: Quick Connect Tab
- Ambient Temperature: Terminal Side: -20°C to +85°C, Actuating Side: -20°C to +55°C
- Storage Temperature: -30°C to +80°C
- Temperature Rise: 30°C Max @ Terminal
- Electrical Rating: 10A, 250V AC / 15A, 125V AC
- Electrical Life Endurance: 10,000 cycles
- Contact Resistance: < 20mΩ
- Insulation Resistance: > 1,000MΩ
- Dielectric Strength: > 1,500V/min
- Push Force for Tabs: 26kg
- Pull Force for Tabs: 210kg
- Operating Force: 550g +100g
- Force for Button: 29kg
- Switch Function: Momentary
- Dimension: Panel cut out thickness 0.8~3mm (0.031"~0.118")
Buy the Buy Premier Farell Rocker Switch Part Number MCRC15KKFT00B Online
Enhance your control systems with this durable non-illuminated round rocker switch. Rated at 10A and suitable for various industrial applications, it features quick connect terminals, a robust polyamide housing, and UL/VDE safety approvals. Perfect for automation, control panels, and equipment requiring reliable momentary switching, this switch offers long-lasting performance with an electrical life of 10,000 cycles. Easy to install with panel cutout options from 0.8 to 3mm, ensuring seamless integration into your projects.
Buy Premier Farell MCRC15KKFT00B now and experience unmatched reliability and performance in industrial control applications.
