MULTICOMP PRO MCSD431R8MU inductor
This high-quality SMD inductor with a 1.8uH inductance and 20% tolerance offers reliable performance at 100kHz. Designed with a ferrite core, it features a resistance of 64mΩ and can handle up to 2.98A DC current. Its compact dimensions (4.5mm x 3.2mm x 4.5mm) make it ideal for space-constrained electronic applications. Operating efficiently across temperatures from -55°C to +130°C, it ensures stable inductance and minimal loss in various industrial and consumer electronics.
MULTICOMP PRO MCSD431R8MU inductor Specifications:
- Inductance: 1.8uH
- Inductance Tolerance: 20%
- DC Resistance Max: 64mΩ
- DC Current Rating: 2.98A
- Core Material: Ferrite
- External Dimensions: 4.5mm x 3.2mm x 4.5mm
- Operating Temperature Range: -55°C to +130°C
- Series: SD43
- Resonant Frequency: 100kHz
- Lead Material: Solder (Lead Free) Sn99.3% / Cu0.7%
- RoHS Compliant
- Wire: @0.29mm x 1P 2QUEWF 155°C
- Number of Pins: 12
- Case Style: SMD
Buy the Multicomp Pro MCSD431R8MU – Reliable Inductor for Industrial Applications
Purchase the multicomp:ro MCSD431R8MU inductor online to ensure high performance and reliability in your electronic projects. Featuring a 1.8uH inductance, 20% tolerance, and a low resistance of 64mΩ, this SMD ferrite core inductor handles up to 2.98A current. Its compact size of 4.5mm by 3.2mm by 4.5mm makes it suitable for space-constrained applications, with an operating temperature range from -55°C to +130°C. Order now for quick delivery and technical support.
Get multicomp:ro MCSD431R8MU today—built for precision and long-lasting durability in compact electronic designs.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCSD431R8MU?
You can click on the BUY or RFQ button to purchase MCSD431R8MU from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCSD431R8MU?
You can download the MCSD431R8MU datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCSD431R8MU?
MULTICOMP PRO
