MULTICOMP PRO MCSD54100MU High-Frequency SMD Inductor
The multicomp RC inductor features a 10H inductance with a tolerance of 120%, supporting high current ratings of 1.44A with a DCR maximum of 0.10Ω. Designed for surface-mount applications, it has a ferrite core, dimensions of 5.8mm width, 5.2mm depth, and 4.5mm height, with a resonance at 100kHz. Operating across -55°C to +130°C, it employs lead-free solder and is RoHS compliant, suitable for lightweight, high-frequency electronic circuits requiring reliable inductance and compact size.
MULTICOMP PRO MCSD54100MU High-Frequency SMD Inductor Specifications:
- Inductance: 10H
- Inductance Tolerance: 120%
- DC Resistance Max: 0.10Ω
- DC Current Rating: 1.44A
- Operating Temperature: -55°C to +130°C
- Core Material: Ferrite
- External Dimensions: Width 5.8mm, Depth 5.2mm, Height 4.5mm
- Resonant Frequency: 100kHz
- Series: MCSD54
- SMD Case Style
- Pins: 2
- Lead Spacing: 2mm
- Solder Type: Lead-Free Sn99.3%/Cu0.7%
- RoHS Compliant
Buy the Buy Multicomp RC Part Number MCSD54100MU Online
Enhance your electronic projects with this high-quality surface-mount 10H ferrite core inductor capable of handling up to 1.44A current. Its compact SMD form factor, RoHS compliance, and operating temperature range from -55°C to +130°C make it versatile for high-frequency circuits, power supplies, and noise filtering. The 100kHz resonant frequency ensures optimal performance in your electronic assemblies. Purchase online today for reliable, lightweight inductors that meet demanding specifications and support your innovative design needs.
Buy Multicomp RC MCSD54100MU now and experience reliable high-frequency inductance for your electronic designs.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCSD54100MU?
You can click on the BUY or RFQ button to purchase MCSD54100MU from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCSD54100MU?
You can download the MCSD54100MU datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCSD54100MU?
MULTICOMP PRO
