MULTICOMP PRO MCTR100JDD0100 Power Resistor
The MCTR100 power resistor is a high-performance, 100-watt, TO-247 style component designed for demanding applications such as gate resistors in power supplies, snubbers, and load dumping in CRT monitors. It features a molded, electrically isolated, non-inductive case with a heat sink mounting option. With a case temperature rating up to 175°C and a resistance range of 0.050Ω to 19Ω, it provides reliable performance in high-temperature environments. Its construction includes a alumina substrate and tinned copper lead for durability and easy mounting, making it suitable for industrial and electronic applications requiring high power dissipation and stability.
MULTICOMP PRO MCTR100JDD0100 Power Resistor Specifications:
- Power Rating: 100 Watts at 25°C case temperature
- Package Style: TO-247
- Resistance Range: 0.050Ω to 19Ω
- Resistance TCR (PPM/°C): +50, -100, +200
- Maximum Operating Voltage: 700V
- Dielectric Strength: 1800V AC
- Insulation Resistance: 10 GΩ min.
- Working Temperature: -65°C to +175°C
- Construction: Alumina substrate, molded case, tinned copper leads
- Dimensions: Embossed in inches and millimeters, case temperature rating up to 175°C
- Environmental Resistance: Load life, moisture resistance, thermal shock, vibration tested
- Lead Material: Tinned copper
- Maximum Torque: 0.9 Nm
Buy the Buy multicomp power resistor Part Number MCTR100JDD0100 Online
Experience the reliability and high-performance power dissipation of the multicomp power resistor MCTR100JDD0100. This 100-watt resistor features a TO-247 package, heat sink mounting capability, and a broad resistance range suitable for industrial and electronic applications. Its molded, electrically isolated case ensures durability and safety in high-temperature environments, while its construction with alumina substrate and tinned copper leads offers excellent thermal and electrical performance. Perfect for applications such as power supplies, snubbers, and voltage regulation, the MCTR100 provides robust, long-lasting operation, ensuring your system’s efficiency and reliability.
Buy multicomp power resistor MCTR100JDD0100 now and experience high power dissipation, reliable performance, and durable construction for demanding applications.
