MULTICOMP-PRO MCTR35JDD0560 Power Resistor
The multicomp power resistor is a high-capacity, TO-220 style device designed for efficient heat dissipation and electrical isolation. Rated for 35 watts at 25°C, it features a mold for protection, non-inductive design, and single screw mounting for easy installation on heat sinks. Suitable for switching power supplies, RF power amplifiers, voltage regulation, and automated machinery, it offers an operating temperature range from -65°C to +150°C, with a resistance range from 0.10Ω up to 1kΩ or more. Its robust construction ensures reliability in demanding applications.
MULTICOMP-PRO MCTR35JDD0560 Power Resistor Specifications:
- Power Rating: 35 Watts at 25°C
- Heat sink mounted design with single screw
- TO-220 style power package
- Electrical isolation case
- Operating Voltage: Max 350V
- Resistance Range: <1Ω (up to 1kΩ or more)
- TCR: ±50 PPM/°C to ±300 PPM/°C
- Dielectric Strength: 1800VAC
- Insulation Resistance: ≥10 GO
- Working Temperature: -65°C to +150°C
- Temperature Coefficient of Resistance: Refer to specifications
- Environmental Test: Load Life ±1% over 2000 hours, Short Time Overload, Damp Heat, Thermal Shock
- Material: Tinned copper leads, molded protective case
- Maximum Torque: 0.9 N-m
- Soldering: Flow at 260°C for 10 seconds, Iron at 410°C for 5 seconds
- Dimensions: approximately 30 x 40 mm with mounting features
Buy the Buy Multicomp Power Resistor Part Number MCTR35JDD0560 Online
Enhance your electronic projects with the high-performance multicomp power resistor, rated for 35 watts with a robust TO-220 package. Perfect for power supplies, RF amplification, voltage regulation, and automation controllers, its non-inductive design ensures stability and minimal signal distortion. Easy to mount with a single screw, it features excellent thermal management and electrical isolation, making it ideal for demanding environments. Reliable and durable, this resistor guarantees consistent performance over extended operational periods, ensuring your devices run smoothly and efficiently.
Buy Multicomp power resistor MCTR35JDD0560 now and experience unmatched reliability and performance in high-power applications.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MCTR35JDD0560?
You can click on the BUY or RFQ button to purchase MCTR35JDD0560 from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MCTR35JDD0560?
You can download the MCTR35JDD0560 datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MCTR35JDD0560?
MULTICOMP-PRO
