MULTICOMP PRO MCTR50FDD4700 Power Resistor
The multicomp power resistor delivers 50 watts of continuous power at 25°C with a TO-220 package and molded case for protection and easy mounting. Its non-inductive design makes it suitable for high-frequency switching power supplies, pulsing applications, UPS systems, and voltage regulation. Constructed on an alumina substrate with a resistive layer and lead, the resistor is electrically isolated, RoHS compliant, and features a temperature range from -65°C to +150°C. Rated for voltages up to 350V, it offers excellent thermal and electrical characteristics for demanding electronic environments.
MULTICOMP PRO MCTR50FDD4700 Power Resistor Specifications:
- Power Rating: 50 Watts at 25°C case temperature
- Voltage Rating: 350V max.
- Operating Temperature Range: -65°C to +150°C
- Case Material: Molded case with alumina substrate
- Resistance Range: < 10 ohms, resistance value with tolerance codes (D: +50, R100: 0.10, etc.)
- Dielectric Strength: 1,800V AC
- Insulation Resistance: 10 GO min.
- Resistance Temperature Coefficient: Referenced to 25°C, AR at +105°C
- Short Time Overload: AR ≤0.3% at 2 times rated power for 5 seconds
- Load Life: AR +1.0% over 2000 hours at rated power
- Thermal Shock: AR +0.3% between -65°C to +150°C, 100 cycles
- Solderability: 90% min. coverage at 245°C for 3 seconds
- Terminal Strength: 2.4N pull test
- Vibration and High Frequency: AR 40.2%, 20g peak
- Lead Material: Tinned copper
Buy the Buy multicomp Power Resistor Part Number MCTR50FDD4700 Online
Explore the advanced multicomp power resistor rated for 50 watts, ideal for high-frequency switching, pulsing, UPS, and voltage regulation applications. Its TO-220 package and molded case design ensure durability and ease of mounting in various electronic setups. With a wide temperature range from -65°C to +150°C and a dielectric strength of 1,800V AC, this resistor guarantees reliable operation under demanding conditions. Perfect for electronic engineers seeking a high-performance, RoHS compliant component for power management projects.
Buy multicomp MCTR50FDD4700 now and experience unmatched reliability and high current performance for demanding power applications.
