MULTICOMP PRO MCTR50FDE1001 Power Resistor
The multicomp power resistor offers a robust TO-220 package designed for high power applications up to 50 watts at 25°C with a heat sink. It features a molded case for protection, non-inductive design suitable for high-frequency and pulsing applications, including switching power supplies, UPS, and voltage regulation. Constructed with alumina substrate and tinned copper leads, it provides excellent electrical insulation, high dielectric strength, and thermal stability. Rated for operation up to 150°C with a maximum voltage of 350V, ensuring reliability in demanding environments.
MULTICOMP PRO MCTR50FDE1001 Power Resistor Specifications:
- Power Rating: 50 Watts at 25°C case temperature
- Case Material: Molded plastic with alumina substrate
- Lead Material: Tinned copper
- Maximum Operating Voltage: 350V
- Dielectric Strength: 1,800V AC
- Insulation Resistance: 10 GΩ min.
- Temperature Range: -65°C to +150°C
- Thermal Design: Heat sink mounted, case temperature critical
- Resistance Range: < 10Ω
- TCR: Referenced to 25°C, ±50 PPM/°C
- Environmental Tests: Load life +1.0% AR for 2000 hours, thermal shock +0.3%, vibration 20g peak
- RoHS Compliance: Yes
Buy the Buy multicomp Power Resistor Part Number MCTR50FDE1001 Online
Order the multicomp Power Resistor MCTR50FDE1001 online today to ensure high efficiency and durability in your electronic projects. This 50-watt, non-inductive resistor is perfect for power supplies, UPS systems, and pulsing applications. Its rugged construction with molded case and alumina substrate guarantees excellent thermal and electrical performance. Suitable for applications requiring high voltage and temperature resilience, it offers reliable operation with strict compliance to RoHS standards. Secure your supply of this essential components for robust and stable power management.
Buy multicomp MCTR50FDE1001 now and experience unmatched reliability and performance in high-power, high-frequency applications.
