MULTICOMP PRO MCTR50FDE4701 Power Resistor
The multicomp power resistor is a 50-watt, TO-220 style component designed for use in switching power supplies, voltage regulation, and pulsing applications. It features a molded case for protection, thermal efficiency with heat sink mounting, and a non-inductive design suitable for high-frequency circuits. Constructed on an alumina substrate with tinned copper leads, it offers reliable electrical performance, a maximum operating voltage of 350V, and high endurance over temperature ranges from -65°C to +150°C. RoHS compliant and designed for durable, high-power applications.
MULTICOMP PRO MCTR50FDE4701 Power Resistor Specifications:
- Power Rating: 50 Watts at 25°C case temperature
- Maximum Operating Voltage: 350V
- Dielectric Strength: 1,800V AC
- Insulation Resistance: ≥10 GΩ
- Working Temperature Range: -65°C to +150°C
- Temperature Coefficient of Resistance: Referenced to 25°C, AR +0.3%
- Resistance Range: <10Ω available, tolerance codes D +50/100, J +5%, K +10%
- Lead Material: Tinned Copper
- Case Material: Molded with alumina substrate
- Dimensions: Refer to datasheet for detailed size specifications
- RoHS: Compliant
- Environmental Testing: Load life +1.0% over 2000 hours, thermal shock, vibration, and damp heat tested
Buy the Buy multicomp Power Resistor Part Number MCTR50FDE4701 Online
Purchase the multicomp power resistor MCTR50FDE4701 online and enhance your electronic projects with a high-capacity, reliable component designed for demanding applications. With a robust 50W power rating, non-inductive construction, and heat sink mounting options, this resistor excels in switching power supplies, voltage regulation, and pulsing circuits. Its durable molded case, wide temperature range, and RoHS compliance make it suitable for industrial, commercial, and high-frequency uses. Simply add this resistor to your cart and ensure dependable performance in your next project.
Order your multicomp Series MCTR50FDE4701 power resistor today and ensure your high-power circuits operate reliably with excellent heat dissipation and stability.
