MULTICOMP PRO MP000438 Super Blue LED Lamp
This 5mm round LED lamp emits super blue light with a peak wavelength of 470nm, ideal for indicator and display applications. It features InGaN dice material, a water-clear lens, and a 16° viewing angle with luminous intensity up to 4000mcd. Operating at 20mA with a forward voltage of 3.2-3.6V, it supports a temperature range of -40°C to +85°C and is RoHS and RoHS-compliant. Suitable for various electronic and illumination projects, it offers reliable performance with a maximum power dissipation of 85mW and high electrostatic discharge immunity.
MULTICOMP PRO MP000438 Super Blue LED Lamp Specifications:
- Dice Material: InGaN
- Emitted Colour: Super Blue
- Lens Colour: Water Clear
- Peak Wavelength: 470 nm
- Viewing Angle: 16 Deg.
- Luminous Intensity: 4000mcd
- Forward Voltage: 3.2 - 3.6 V
- Power Dissipation: 85 mW
- Operating Temperature Range: -40°C to +85°C
- Reverse Voltage: 5 V
- Reverse Current: 10 nA
- Electrostatics Discharge (ESD): 200 V
- Lead Soldering Temperature: 260°C for 5 seconds
- Maximum Forward Current: 100 mA
- Recommended Operating Current: 20 mA
- Peak Emission Wavelength: 470 nm
- Spectral Line Half-Width: 45 nm
Buy the Premier Multicomp Series Super Blue LED: 470nm 5mm Round Lamp
Purchase the Super Blue LED Lamp online today for reliable performance and high brightness in your electronic projects. With a 470nm wavelength, 16° viewing angle, and 4000mcd intensity, this 5mm LED is perfect for indicators and displays. It features InGaN dice, water-clear lens, and supports operating temperatures from -40°C to +85°C. Designed for durability with RoHS compliance, it offers a forward voltage of 3.2-3.6V and maximum current of 100mA. Ideal for professional and hobbyist applications, ensuring long-lasting illumination.
Get Premier Multicomp Series Super Blue LED today—built for brightness and long-lasting performance in indicator applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP000438?
You can click on the BUY or RFQ button to purchase MP000438 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP000438?
You can download the MP000438 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP000438?
MULTICOMP PRO
