MULTICOMP PRO MP000451 Ultra Red LED Lamp
This 3mm round LED lamp in Ultra Red emits at 653nm with a viewing angle of 36 degrees and luminous intensity of 500mcd at 20mA. Featuring AllnGaP dice material, it has a forward voltage of 1.7-2.4V and power dissipation of 85mW. Designed for reliable operation from -40°C to +85°C, it supports a maximum reverse voltage of 5V with a reverse current of 10nA. Suitable for indicator lights, displays, and signaling applications, this LED is RoHS compliant and solderable at 260°C for 5 seconds, ensuring durability and efficiency.
MULTICOMP PRO MP000451 Ultra Red LED Lamp Specifications:
- Dice Material: AllnGaP
- Emitted Colour: Ultra Red
- Lens Colour: Red Transparent
- Peak Wavelength: 653 nm
- Viewing Angle: 36 Degrees
- Luminous Intensity: 500 mcd at 20mA
- Forward Voltage: 1.7 - 2.4 V
- Power Dissipation: 85 mW
- Peak Forward Current: 100 mA (Duty 1/10 at TkHz)
- Recommended Operating Current: 20 mA
- Reverse Voltage: 5 V
- Reverse Current: 10 nA (VR = 5V)
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature Range: -40°C to +100°C
- Lead Soldering Temperature: 260°C for 5 seconds
Buy the Buy multicomp Ultra Red Part Number MP000451 Online
Purchase the Ultra Red LED lamp today to enhance your electronic projects with high brightness, excellent durability, and precise color emission at 653nm. Its reliable performance, low forward voltage, and RoHS compliance make it ideal for indicators, displays, and signaling systems. Easy to solder and operate across a wide temperature range, this 3mm LED ensures long-lasting functionality for industrial and consumer applications. Shop online now for fast delivery and competitive pricing on this essential lighting component.
Buy multicomp Ultra Red LED lamp MP000451 now and experience unmatched reliability and performance in signaling and indicator applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP000451?
You can click on the BUY or RFQ button to purchase MP000451 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP000451?
You can download the MP000451 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP000451?
MULTICOMP PRO
