MULTICOMP PRO MP002477 D-Sub Connector
The MP sealed D-Sub series of connectors are environmentally sealed, rugged, and suitable for demanding applications. Designed for panel-mount installation, they are fully rear potted to ensure protection even when unmated or without the sealing cap. Available in standard 9-pin and high-density 15-pin configurations, these connectors feature screw mating, gold-plated contacts, and are rated IP67 for waterproof and dustproof sealing. They are ideal for use in audio, automation and process control, as well as communications and networking applications.
MULTICOMP PRO MP002477 D-Sub Connector Specifications:
- IP Rating: IP67
- Suitable Cable OD: 4mm to 8mm
- Recommend Cover Torque: 6 to 7 Kgf-cm
- Recommend Gland Nut Torque: 9 to 10 Kgf-cm
- Housing Material: Thermoplastic, Black
- Contacts Material: Copper Alloy, Gold or Au Plated
- Shell Material: SPCC or Cold Roll Steel, Ni Plated
- Sealing Material: EPDM, Black
- Suitable Panel Thickness: 0.8mm to 2mm
- Screw Size: #4-40
- Dimensions: varied per model, e.g., 25.0mm, 28.2mm, 39.4mm lengths
- Rated for environmental sealing, waterproof and dustproof IP67
- Includes rubber seals, gaskets, and stainless or nickel-plated fasteners for durability
- Field-installable and rear potted for protection in demanding environments.
Buy the MultiComp IP67 Reliable D-Sub Connectors for Industrial Applications
Enhance your designs with our waterproof and dustproof D-Sub connectors, featuring IP67 rating and gold-plated contacts for reliable performance. Ideal for industrial, automation, and networking applications, these panel-mount connectors are designed for demanding environments. Easy to install with screw mating and rear potted construction, they provide excellent protection and durability. Purchase online now to secure high-quality, environmentally sealed connectors that meet your project's ruggedness and reliability needs, ensuring long-lasting connectivity in challenging conditions.
Order your MultiComp Series MP002477 D-Sub connector today and ensure your projects benefit from robust, waterproof, and dependable connectivity solutions.
