MULTICOMP PRO MP002483 Sealed Industrial D-Sub Connector
The MP Series sealed D-Sub connectors are built for harsh environments, providing environmental sealing and rugged durability. These panel-mount connectors are fully rear potted for protection when unmated or with the sealing cap removed. Available in 9-pin and 15-pin high-density configurations, they feature screw-mating and gold-plated contacts for dependable signal transmission. Rated IP67, they are ideal for audio, automation, process control, communications, and networking, ensuring reliable performance in demanding industrial applications.
MULTICOMP PRO MP002483 Sealed Industrial D-Sub Connector Specifications:
- IP Rating: IP67
- Suitable Cable OD: 4mm to 8mm
- Material Housing: Thermoplastic, Black
- Contacts: Copper Alloy, Gold or Au Flash Plated
- Shell: Cold Roll Steel, Ni Plated
- Seal: EPDM, Black
- Gasket: EPDM, Black
- Recommended Cover Torque: 6 to 7Kgf-cm
- Gland Nut Torque: 9 to 10Kgf-cm
- Suitable for Panel Thickness: 0.8mm to 2mm
- Minimum Screw Length: 5.0mm; Maximum Screw Length: 6.0mm
- Dimensions vary per configuration but generally include panel cut-out compatibility and robust construction suitable for professional applications
Buy the Multicomp Series D-Sub IP67 Connector: MP002483
Order the reliable and rugged sealed D-Sub connector online today to ensure optimal performance in demanding industrial applications. These IP67-rated connectors are designed with fully rear potted construction, gold-plated contacts, and robust materials suitable for harsh environments. Perfect for automation, communications, and networking, they offer easy panel mounting with compatible dimensions for a secure fit. Enhance your system's reliability by purchasing this high-quality connector online and benefit from quick delivery and superior support for your industrial needs.
Buy Multicomp Series MP002483 now and experience unmatched reliability and performance in demanding industrial environments.
