MULTICOMP PRO MP002739 M12 Push-Pull Connector
The MP M12 push-pull connectors are chrome-plated brass connectors designed for durability and aesthetic appeal. Suitable for demanding environments, they support cable-to-cable and cable-to-panel connections across various configurations, including panel, cable, and inline mounts. Featuring a quick connect push-pull mechanism, IP67 weather resistance, and compatibility with 12mm panel cut-outs, these connectors serve automation, medical, security, testing, and industrial automation sectors. Available with 2, 4, 5, or 7 poles, they provide reliable solder terminal connections and excellent environmental protection for diverse demanding applications.
MULTICOMP PRO MP002739 M12 Push-Pull Connector Specifications:
- Shell Material: Brass with chrome plating
- Insert Material: PPS, Max. Temperature 260°C
- Contact Material: Brass with gold plating
- IP Rating: IP67
- Mating Cycle: 500
- Temperature Range: -40°C to +85°C
- Insulation Resistance: 2000 MΩ
- Number of Contacts: 2, 4, 5, 7
- Rated Current: 13 A (2 poles), 5 A (others)
- Rated Voltage: 250 V (2 poles), 200 V, 180 V, 125 V (others)
- Test Voltage: 1500 V (2 poles), 1000 V (others)
- Contact Resistance: 2.5 mΩ (2 poles), 5 mΩ (others)
- Wire Size: 0.75/18 AWG (approximate)
- Minimum Panel Cutout: 3.5 mm
- Outer Diameter Range: 4-6.5 mm or 5-8 mm
- Dimensions: Approximate mounting diameter 19/20 mm, length varies with configuration
Buy the Buy Multicomp M12 Push-Pull Circular Connectors Part Number MP002739 Online
Enhance your projects with the versatile and durable M12 Push-Pull Circular Connectors from Multicomp. These connectors feature a secure push-pull coupling, IP67 weather resistance, and multiple configuration options, making them ideal for automation, medical, security, and industrial applications. Easy to install with solder terminals and supporting cable-to-cable or cable-to-panel connections, they provide reliable performance in demanding environments. Purchase online now to ensure your systems remain connected securely and efficiently, backed by trusted quality and fast shipping.
Order your Multicomp Series MP002739 M12 Push-Pull Circular Connector today and ensure reliable, quick-connect solutions for industrial automation and equipment protection.
