MULTICOMP PRO MP004310 Ceramic Cartridge Fuse
This fast-acting ceramic cartridge fuse features a 6.3mm diameter and 32mm length, suitable for circuit protection in various electrical applications. It is RoHS compliant, UL Listed, CSA Certified, and PSE approved, ensuring high safety and reliability standards. Designed for quick response in overcurrent conditions, it operates within a temperature range of 1-55°C to 125°C. Made from ceramic with nickel-plated brass caps and 0.8 mm wire leads, it handles ratings from 500mA to 30A, with interrupting ratings up to 10,000A at 125V AC/DC. Its compact design ensures easy integration into electronic systems.
MULTICOMP PRO MP004310 Ceramic Cartridge Fuse Specifications:
- Dimensions: 6.3mm diameter x 32mm length
- Body Material: Ceramic
- Caps: Nickel plated brass
- Lead Wire Diameter: 0.8 mm
- Temperature Range: 1-55°C to 125°C
- Rating Range: 500mA to 30A
- Interrupting Rating: Up to 10,000A at 125V AC/DC
- RoHS Compliant
- UL Listed, CSA Certified, PSE Approved
- Voltage Rating: 125V AC/250V AC/DC
- Melting I2t: up to 0.1879 A² sec at lower ratings
- Operating Temperature: -55°C to +125°C
- Recognized component for US and Canada
Buy the Buy multicomp Fast Acting Ceramic Cartridge Fuse Part Number MP004310 Online
Purchase the multicomp ceramic cartridge fuse MP004310 online today to experience dependable circuit protection in your electronic projects. Designed with high-quality ceramic and nickel-plated brass caps, it offers quick response and high interrupting capacity, making it ideal for various electrical and electronic applications. With ratings up to 30A and UL, CSA, and PSE certifications, this fuse guarantees safety and compliance. Shop now to ensure your equipment is protected with this reliable, easy-to-install fuse designed for optimal performance and safety in demanding environments.
Buy multicomp MP004310 now and ensure high reliability and quick circuit protection for your electronic systems.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP004310?
You can click on the BUY or RFQ button to purchase MP004310 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP004310?
You can download the MP004310 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP004310?
MULTICOMP PRO
