MULTICOMP PRO MP004320 Ceramic Cartridge Fuse
The Time-Lag Ceramic Cartridge Fuse with axial leads measures 6.3mm in diameter and 32mm in length. It features a ceramic body with nickel-plated brass caps, suitable for overcurrent protection in electronic circuits. Rated for currents from 800mA to 30A, it withstands operating temperatures from -55°C to 125°C. The fuse has an interrupting rating up to 10,000 amperes at 125V AC and complies with UL, CSA, and PSE standards. Its compact design and reliable performance make it ideal for various electrical and electronic applications.
MULTICOMP PRO MP004320 Ceramic Cartridge Fuse Specifications:
- Body Material: Ceramic
- Cap Material: Nickel Plated Brass
- Lead Wire Diameter: 0.8 mm for ratings 12A and less, 1.0 mm for ratings above 13A, 1.2 mm for ratings above 20A
- Operating Temperature: -55°C to 125°C
- Rated Currents: 800mA to 30A
- Voltage Rating: 125V AC (up to 10,000A interrupting), 250V AC ratings also available
- Interrupting Rating: Up to 10,000A at 125V AC, various ratings based on amperage
- Max Length with Caps on: 33 mm
- Dimensions: Diameter 6.3 mm, Length 32 mm
- Standards Compliance: UL Listed, CSA Certified, PSE
Buy the Buy Multicomp Ceramic Cartridge Fuse Part Number MP004320 Online
Purchase the Multicomp ceramic cartridge fuse MP004320 online today for dependable circuit protection. Designed with a ceramic body and nickel-plated brass caps, it offers high interrupting ratings and compliance with UL, CSA, and PSE standards. Suitable for applications requiring currents from 800mA to 30A and operating temperature ranges from -55°C to 125°C, this fuse ensures safety and durability in electronic and electrical systems. Its compact form factor makes it ideal for various device integrations and repair projects.
Get Multicomp ceramic fuse MP004320 today—compact, reliable overcurrent protection for your electrical circuits.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP004320?
You can click on the BUY or RFQ button to purchase MP004320 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP004320?
You can download the MP004320 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP004320?
MULTICOMP PRO
