MULTICOMP PRO MP004324 Ceramic Cartridge Fuse
The Time-Lag Ceramic Cartridge Fuse is an axial leaded fuse measuring 6.3mm x 32mm, designed for reliable overcurrent protection in electrical circuits. Suitable for ratings from 800mA to 30A, it features a ceramic body with nickel-plated brass caps and leads of varying thicknesses depending on current ratings. The fuse withstands temperatures from -55°C to 125°C and offers high interrupting ratings up to 10,000 amperes at 125V AC. Approved by UL, CSA, and PSE, it's ideal for precise, secure overcurrent protection in various electronic and electrical applications.
MULTICOMP PRO MP004324 Ceramic Cartridge Fuse Specifications:
- Dimensions: 6.3mm diameter x 32mm length
- Body Material: Ceramic
- Caps Material: Nickel-plated Brass
- Lead Wire Diameter: 0.8 mm for 12A and less, 1.0 mm for 13A-19A, 1.2 mm for above 20A
- Operating Temperature: -55°C to 125°C
- Interrupting Rating: Up to 10,000A at 125V AC
- Rated Current: 800mA to 30A
- Rated Voltage: Up to 250V AC/DC depending on model
- Certifications: UL Listed, CSA Certified, PSE
- Part Number: MP004324
Buy the Multicomp Series Time-Lag Ceramic Fuse: MP004324
Order the Ceramic Cartridge Fuse now for reliable overcurrent protection in electronic devices. This axial leaded fuse features a ceramic body, nickel-plated brass caps, and supports current ratings from 800mA to 30A. Suitable for a wide range of applications, it offers exceptional interrupting capacity up to 10,000A at 125V AC, ensuring circuit safety. Manufactured to meet UL, CSA, and PSE standards, purchase online today for fast delivery and quality assurance.
Get Multicomp Series Time-Lag Ceramic Fuse MP004324 today—built for precision and long-lasting durability.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP004324?
You can click on the BUY or RFQ button to purchase MP004324 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP004324?
You can download the MP004324 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP004324?
MULTICOMP PRO
