MULTICOMP PRO MP004328 Ceramic Cartridge Fuse
The Time-Lag Ceramic Cartridge Fuse with axial lead configuration measures 6.3mm by 32mm, suitable for circuits from 800mA up to 30A. Made with ceramic body and nickel-plated brass caps, it features a temperature range of -55°C to 125°C. Its high interrupting rating of 10,000A at 125V AC and 35A at 250V AC ensures reliable circuit protection. The fuse's leads are wire-wrapped, with diameters suitable for ratings above and below 13A, and adhere to safety standards for UL, CSA, and PSE certification, ensuring quality and compliance.
MULTICOMP PRO MP004328 Ceramic Cartridge Fuse Specifications:
- Body Material: Ceramic
- Caps Material: Nickel Plated Brass
- Lead Wire Diameter: 0.8 mm for 12A and less, 1.0 mm for ratings above 13A to 19A, 1.2 mm for above 20A
- Lead Wire Length: 38 ± 2 mm
- Total Fuse Length: 33 ± 0.75 mm
- Maximum Current Rating: 30A, 100% rating
- Interrupting Rating: 10,000 amperes at 125V AC, 35 amperes at 250V AC
- Operating Temperature Range: -55°C to 125°C
- Rated Voltage: 125V AC, 250V AC
- Certification: UL Listed, CSA Certified, PSE Approved
- Dimensions: 6.3mm diameter x 32mm length, including cap height of 6.45mm and ceramic diameter of 5.72mm
- Standards Compliance: RoHS, UL, CSA, PSE
Buy the Multicomp Series Time-Lag Ceramic Fuse: MP004328
Purchase the Multicomp Series ceramic cartridge fuse MP004328 online today to ensure excellent circuit protection. With its high interrupting capacity, robust ceramic body, and certified safety standards, this fuse guarantees dependable performance in electrical systems. Its axial lead design simplifies installation, while its wide current range from 800mA to 30A makes it versatile for various applications. Whether for industrial equipment or electrical panels, buy online now to benefit from fast delivery, trusted quality, and competitive pricing for your safety and operational efficiency.
Buy Multicomp Series MP004328 ceramic time-lag fuse now and experience unmatched reliability and high-current circuit protection for industrial applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP004328?
You can click on the BUY or RFQ button to purchase MP004328 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP004328?
You can download the MP004328 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP004328?
MULTICOMP PRO
