A Premier B2B Part Search
MULTICOMP PRO MP004334 Ceramic Cartridge Fuse
The Time-Lag Ceramic Cartridge Fuse is an axial leaded fuse designed for circuit protection with a 6.3mm x 32mm size, suitable for electrical applications up to 30A and rated at 125V AC. Its ceramic body and nickel-plated brass caps ensure high durability and resistance to temperature variations from -55°C to 125°C. Available in various amperages from 800mA to 30A, this fuse features fast response times and high interrupting ratings, making it ideal for protecting sensitive electronics in industrial and consumer devices.
MULTICOMP PRO MP004334 Ceramic Cartridge Fuse Specifications:
- Size: 6.3mm x 32mm
- Body Material: Ceramic
- Caps Material: Nickel Plated Brass
- Lead Diameter: 0.8 mm for 12A and less, 1.0 mm for 13A-19A, 1.2 mm for above 20A
- Temperature Range: -55°C to 125°C
- Rated Voltage: 125V AC, 250V AC depending on amperage
- Current Rating: 800mA to 30A
- Interrupting Rating: 10,000A at 125V AC, 35A at 250V AC
- Part Number: MP004334
- Compliance: RoHS, UL Listed, CSA Certified
- Lead Length: 38 ±2 mm
- Total Length with Caps: 33 ±0.75 mm
Buy the Buy Multicomp Time-Lag Ceramic Cartridge Fuse Part Number MP004334 Online
Secure your electronic circuitry with the high-reliability Ceramic Cartridge Fuse, ideal for circuit protection in industrial and consumer electronics. This axial lead fuse measures 6.3mm by 32mm, rated from 800mA to 30A at 125V AC, and is constructed with durable ceramic bodies and nickel-plated brass caps. It features excellent impedance characteristics and a high interrupting capacity up to 10,000A at 125V AC, ensuring safety and durability across a wide temperature range from -55°C to 125°C. Trusted and compliant with RoHS, UL, and CSA standards, it is perfect for sophisticated electrical applications.
Order your Multicomp Series MP004334 axial lead fuse today and enhance your circuit protection with reliable high-current capacity and fast response.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP004334?
You can click on the BUY or RFQ button to purchase MP004334 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP004334?
You can download the MP004334 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP004334?
MULTICOMP PRO
