MULTICOMP PRO MP004336 Ceramic Cartridge Fuse
This time-lag ceramic cartridge fuse features axial leaded design with a 6.3mm diameter and 32mm length, suitable for circuit protection in electrical systems. Made from ceramic with nickel-plated brass caps, it provides reliable interrupting ratings up to 10,000 amperes at 125V AC and 750 amperes at 250V AC. The fuse operates within temperatures from -55°C to 125°C and supports ratings from 800mA to 30A. Its compact dimensions and high interruption capacity make it ideal for industrial and electronic applications requiring precise circuit protection.
MULTICOMP PRO MP004336 Ceramic Cartridge Fuse Specifications:
- Body Material: Ceramic
- Cap Material: Nickel Plated Brass
- Diameter of Cap: 6.35mm (0.1mm tolerance)
- Height of Cap: 6.45mm (0.1mm tolerance)
- Diameter of Ceramic: 5.72mm (+0.2mm)
- Lead Wire Diameter: 0.8mm to 1.2mm depending on rating
- Lead Wire Length: 38mm (+2mm)
- Maximum Operating Temperature: 125°C
- Temperature Range: -55°C to 125°C
- Interrupting Rating: Up to 10,000A at 125V AC and 750A at 250V AC
- Ratings: 800mA to 30A, UL Listed, CSA Certified
- Rated Voltage: 125V AC, 250V AC
- Response Time: Time-lag/slow-blow characteristic
- Dimensions: 6.3mm diameter, 32mm length, overall length with caps approximately 33mm
Buy the Buy Multicomp Time-Lag Ceramic Cartridge Fuse Part Number MP004336 Online
Purchase the Multicomp ceramic cartridge fuse MP004336 online to ensure reliable circuit protection in your electrical systems. Its axial leaded design, built from durable ceramic with nickel-plated brass caps, supports ratings up to 30A and interrupting capacities up to 10,000 amperes. Suitable for industrial and electronic applications, it operates efficiently within -55°C to 125°C temperature range. This high-quality fuse is UL listed and CSA certified, providing safety, durability, and optimal performance for your electrical needs.
Buy Multicomp MP004336 now and experience unmatched reliability and high interrupting capacity for circuit protection.
