MULTICOMP PRO MP005705 ceramic cartridge fuse
This fast acting ceramic cartridge fuse is designed for reliable overcurrent protection in electronic circuits. With an 8.2mm x 20mm size and axial leads, it features a ceramic body and nickel-plated brass caps. Suitable for applications requiring quick response times, rated from 1A to 10A with interrupting ratings up to 1500A at 250V AC, it operates efficiently from -55°C to +125°C. Standards compliance includes RoHS, UL, CSA, PSE, KTL, and CCC certifications, ensuring safety and quality for various electronic devices.
MULTICOMP PRO MP005705 ceramic cartridge fuse Specifications:
- Body Material: Ceramic
- Caps: Nickel Plated Brass
- Lead Diameter: 0.65 mm (6.3A and less), 0.8 mm (8A/10A)
- Size: 8.2mm x 20mm
- Operating Temperature: -55°C to +125°C
- Interrupting Rating: 1500A at 250V AC
- Rated Current: 1A to 10A
- Nominal Cold Voltage: 1000V (1A), 500V (2A), 350V (3.15A), 300V (4A), 250V (5A), 200V (6.3A), 200V (8A)
- Resistance Drop: 0.0362mΩ (3.15A), 0.0239mΩ (4A), 0.0185mΩ (5A), 0.014mΩ (6.3A), 0.0098mΩ (8A)
- Agency Approvals: Recognized Component, TUV, PSE, KTL, CCC
- Response Time: 10ms to 300ms depending on current
- Max Voltage Rating: 1000V
Buy the Buy Multicomp Ceramic Cartridge Fuse Part Number MP005705 Online
Enhance your electronic safety with our high-quality ceramic cartridge fuse. Rated for 1A to 10A current, this fast acting fuse provides reliable overcurrent protection for various appliances and systems. Its ceramic body ensures durability and heat resistance, while the nickel-plated brass caps offer excellent conductivity. Suitable for a wide temperature range from -55°C to +125°C, it meets multiple international safety standards including RoHS, UL, and CSA. Purchase online today for quick delivery and secure circuit safeguarding.
Buy Multicomp ceramic cartridge fuse MP005705 now and ensure reliable circuit protection with fast acting response under high thermal and electrical loads.
