MULTICOMP-PRO MP3702V2TGG MMCX Right Angle Connector
This MMCX right angle plug is engineered for high-frequency RF applications, offering low leakage and reliable solder termination. Its gold-plated brass body and contact ensure excellent conductivity and durability, supporting frequencies up to 6GHz. Designed with PTFE insulation and a gold-plated contact, it ensures minimal signal loss and high impedance stability. The compact right angle design facilitates easy installation in tight spaces, making it ideal for communication systems and industrial RF setups. Certified per BS EN 12234, this connector guarantees consistent performance in demanding environments.
MULTICOMP-PRO MP3702V2TGG MMCX Right Angle Connector Specifications:
- Connector Type: MMCX Coaxial
- Body Style: Right Angle Plug
- Coaxial Termination: Solder
- Impedance: 50Ω
- Contact Material: Beryllium Copper
- Contact Plating: Gold
- Frequency Max: 6GHz
- Connector Mounting: Cable
- Body Plating: Gold
- Insulator Material: PTFE
- Material: Brass
- VSWR: 1.3
- Connector interface per BS EN 12234
- Dimensions: 40.3 mm length, diameter 3.5 mm, insulator diameter 2.3 mm, detailed measurements include 1.2 mm strip dimension and 93.2 mm connection length
- Environmental: Suitable for RF communication and industrial applications, ensuring durability and stable electrical performance.
Buy the Multicomp Series RF Connector: MMCX Right Angle Plug MP3702V2TGG
Enhance your RF and industrial communication systems with this high-quality MMCX right angle connector. Featuring gold plating for superior conductivity and durability, it supports frequencies up to 6GHz, with low VSWR for efficient signal transmission. Its compact design with solder termination makes installation straightforward in tight spaces. Made from durable brass and PTFE insulator, it guarantees reliable performance and long-term stability in demanding environments. Perfect for professional applications; order online today for fast delivery and premium quality assurance.
Order your Multicomp Series MMCX Right Angle Plug MP3702V2TGG today and enhance your RF communication and industrial setups with reliable, high-quality connectors.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MP3702V2TGG?
You can click on the BUY or RFQ button to purchase MP3702V2TGG from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MP3702V2TGG?
You can download the MP3702V2TGG datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MP3702V2TGG?
MULTICOMP-PRO
