MULTICOMP-PRO MPMLR100V470JNPOTB25 Multilayer Ceramic Capacitors
Our Radial Leaded Multilayer Ceramic Capacitors offer excellent moisture and shock resistance with epoxy coating, suitable for computer, telecommunication, industrial control, and instrumentation applications. With voltage options up to 100V DC and a capacitance range from 47pF to 0.1uF, they feature NPO, X7R, and Y5V dielectrics. Widely used in electronic circuits, these capacitors have robust mechanical features including solder-coated copper leads and conformal epoxy coating. They adhere to RoHS standards and are available in bulk or tape & reel packaging for efficient PCB assembly, ensuring durability and reliability in demanding environments.
MULTICOMP-PRO MPMLR100V470JNPOTB25 Multilayer Ceramic Capacitors Specifications:
- Capacitance Range: 47pF to 0.1uF
- Capacitance Tolerance: NPO: ±45%, X7R: +10%, Y5V: +420%
- Working Voltage: 50V DC, 100V DC
- Temperature Range: NPO: -55°C to +125°C, X7R: -55°C to +125°C, Y5V: -10°C to +85°C
- Insulation Resistance: NPO, X7R: ≥100MΩ or 1000pF at 25°C; Y5V: ≥10GΩ or 10000pF at 25°C
- Mechanical: Conformal epoxy coating, solder-coated copper leads
- Dissipation Factor: NPO: ≤0.1%, X7R: ≤2.5%, Y5V: ≤7% at 25°C
- Dielectric Strength: 250% rated voltage (NPO, X7R), 200% (Y5V)
- Life: 200% rated voltage at +125°C (NPO, X7R), 150% at +85°C (Y5V)
- Package: Bulk, Tape & Reel, Leaded, 2.54mm pitch
- Certifications: RoHS compliant, MIL-STD-202 solderability
- Size: 2.54mm pitch, Case sizes vary, e.g., 0.15x0.15x0.1 inches
- Lead Material: Solder-coated copper
- Environmental: Salt spray, humidity resistant
Buy the Ceramic Multilayer Series Capacitors: MPMLR100V470JNPOTB25
Purchase Ceramic Multilayer Capacitors online today to ensure your electronic projects and industrial systems benefit from high reliability, stable performance, and exceptional moisture resistance. Designed with RoHS compliance and available in bulk or tape & reel for efficient assembly, these capacitors are ideal for demanding applications across computing, telecommunication, and instrumentation sectors. Secure your supply of robust, high-voltage, high-temperature capacitors that guarantee superior electrical performance and long-lasting reliability in harsh environments. Buy now for seamless integration and enhanced circuit stability.
Get Ceramic Multilayer Capacitors MPMLR100V470JNPOTB25 today—built for durability and precision in electronic applications.
