MULTICOMP PRO MPPT466J45W86EA AC Filter Capacitor
These three-phase AC filter film capacitors are designed for power factor correction and noise filtering in industrial electrical systems. Constructed with metallized polypropylene film, they feature self-healing properties and anti-explosion safety designs with overpressure tear-off fuses. Operating within a temperature range of -40°C to +70°C, rated at 640VAC or 750VAC, and compatible with 50Hz or 60Hz frequencies, they ensure reliable performance under demanding conditions. Their compact dimensions and robust construction make them ideal for energy-efficient filtering and stabilization in power conversion and industrial automation.
MULTICOMP PRO MPPT466J45W86EA AC Filter Capacitor Specifications:
- Operating Temperature Range: -40°C to +70°C
- Rated Voltage Urms: 640VAC or 750VAC
- Rated Frequency: 50Hz/60Hz
- Capacitance Tolerance: ±5%
- Construction: Metallized polypropylene film
- Features: Self-healing, anti-explosion design, overpressure tear-off fuses
- Dimensions (approximate): 43.5mm x 44.5mm x 35mm (for 3x46uF, 640VAC)
- Connection Type: Triangle connection
- Maximum Noise Inductance: 100nH
- Maximum Rated Current: 50A
- Mounting: M5 terminals
- Weight: approximately 0.45kg (for model MPPT-466J/45W86EA)
Buy the Multicomp Reliable AC Filter Capacitors for Industrial Applications
Enhance your industrial electrical systems with reliable three-phase AC filter capacitors designed for power correction and noise filtering. Constructed with metallized polypropylene film, these robust units feature self-healing technology and anti-explosion safety features with overpressure tear-off fuses. Rated for 640VAC or 750VAC and operating at -40°C to +70°C, they ensure high performance and safety in demanding environments. Compact and easy to install, they are ideal for energy-efficient power factor correction, noise suppression, and stabilization in industrial automation and power conversion applications.
Order your multicomp series MPPT-236J53W76EA or MPPT-466J/45W86EA today and give your projects the dependable quality they deserve for noise filtering and power stabilization.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MPPT466J45W86EA?
You can click on the BUY or RFQ button to purchase MPPT466J45W86EA from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MPPT466J45W86EA?
You can download the MPPT466J45W86EA datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MPPT466J45W86EA?
MULTICOMP PRO
