MULTICOMP-PRO MPWF1215S3W DC-DC Converter
The 3W isolated DC to DC converter is designed for versatile applications requiring high efficiency and compact size. It features an ultra-wide 8:1 input voltage range, stable regulated single and dual outputs, and an industry-standard SIP package. With efficiencies reaching up to 79% and a 3000VDC input-output isolation test voltage, it ensures reliable performance in medical, industrial, power, and communication fields. Operating across -40°C to +105°C, it includes protections like input under-voltage, output short circuit, and over-current, making it suitable for demanding environments while conforming to RoHS standards.
MULTICOMP-PRO MPWF1215S3W DC-DC Converter Specifications:
- Input Voltage Range: 4.5V to 36V or 5V to 12V, 15V, 24V, 48V options
- Output Power: 3W
- Efficiency: Up to 79%
- Isolation Voltage: 3000VDC
- Operating Temperature: -40°C to +105°C
- No-load Power Consumption: as low as 0.12W
- Input Under-voltage Protection: Yes
- Output Short Circuit Protection: Yes
- Over-current Protection: Yes
- Dimensions: 22mm x 9.5mm x 12mm
- Pin Configuration: Industry standard SIP pinout
- Soldering Resistance: 10 seconds at temperature +300°C
- Vibration Resistance: 5G along X, Y, Z axes
- Slew Rate: PWM mode, 300 kHz switching frequency
- MTBF: 1000 hours (MIL-HDBK-217F at 25°C)
- Operating Humidity: 5-95% RH
- Storage Temperature: -55°C to +125°C
- Ingress Resistance: Input-output resistance 1000 MΩ at 500VDC
- Insulation Capacitance: 40 pF at 100kHz/0.1V
- Compliance: RoHS, EN62368, CISPR32/EN55032
- Material: Flame-retardant black plastic (UL94-V0)
Buy the Buy Multicomp 3W Isolated DC-DC Converter Part Number MPWF1215S3W Online
Purchase the versatile 3W isolated DC-DC converter MPWF1215S3W online today to ensure efficient power transfer in industrial, medical, and communication systems. This compact device features an ultra-wide input range from 4.5V to 36V, delivering up to 79% efficiency, and includes essential protections like input under-voltage, output short circuit, and over-current. Its 3000VDC isolation makes it ideal for demanding environments, and its RoHS compliance guarantees environmentally responsible manufacturing. Easy to install with industry-standard pinouts, ensuring high performance and long-term durability.
Get Multicomp 3W isolated DC-DC converter MPWF1215S3W today—built for reliable power conversion with high efficiency and robust protections.
