MULTICOMP PRO SBR2516 Three Phase Bridge Rectifier
The Silicon Passivated Three Phase Bridge Rectifier is designed for high-current applications, featuring diffused junctions, low forward voltage drop, and high surge current capability. Encased in epoxy with a heat sink, it offers reliable performance and is ideal for printed circuit boards, supporting resistive, inductive, and capacitive loads with significant voltage ratings up to 1600V. Operating between -55°C and +160°C, it ensures maximum heat transfer with bolt-down mounting, making it suitable for industrial power conversion and rectification tasks.
MULTICOMP PRO SBR2516 Three Phase Bridge Rectifier Specifications:
- Maximum Repetitive Voltage VRRM: 50V to 1600V depending on model
- Peak Non-Repetitive Reverse Voltage VrsM: 75V to 1700V
- Peak Surge Current: 375A @ 8.3ms, 360A @ 10ms
- Maximum Average Forward Current: 25A
- Peak Forward Voltage Drop: 1.4V at 12.5A/17.5A
- Thermal Resistance Junction to Case: 1.42 KW
- Thermal Resistance Case to Heatsink: 0.2
- Operating Temperature Range: -55°C to +160°C
- Storage Temperature Range: -55°C to +160°C
- RMS Isolation Voltage: 2,500V
- Mounting: Bolt down with thermal compound, torque up to 20 in-lbs
- Dimensions (approx.): 23.8mm diameter, 24.1mm length, with mounting hole of 5.0mm diameter
Buy the Farnell SBR2516 – Reliable Bridge Rectifier for Industrial Applications
Enhance your power conversion systems with the Farnell SBR2516 Three Phase Bridge Rectifier, offering high current capacity, robust construction, and excellent thermal performance. Easily mounted with bolt-down capability, it guarantees reliable operation across a wide temperature range of -55°C to +160°C. Suitable for industrial power supplies, this rectifier features low forward voltage drop, high surge current capability, and high voltage ratings up to 1600V, making it a perfect choice for demanding applications in manufacturing, automation, and power engineering.
Order your Farnell Series SBR2516 1600V Silicon Passivated Three Phase Bridge Rectifier today and give your projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy MULTICOMP PRO SBR2516?
You can click on the BUY or RFQ button to purchase SBR2516 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part SBR2516?
You can download the SBR2516 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of SBR2516?
MULTICOMP PRO
