MURATA POWER SOLUTIONS DMR35DCMA4DC1R DC Milliammeter
The DMR35-DCxA series is a DC milliammeter designed for measurement ranges of 300 to 1000 mA, powered by 9 to 32 VDC. It features a bright, easily readable red LED display with up to three and a half digit measurements and a bar-graph scale for visual indication. The device offers 0.8% measurement accuracy and incorporates low burden voltage internal shunt resistors for precise readings. Users can adjust the display brightness as needed. It serves as a mechanical drop-in replacement for common analog meters and comes with a two-year warranty. Please note that due to high market demand, lead times may extend and delivery dates could fluctuate. This product is not eligible for discounts.
MURATA POWER SOLUTIONS DMR35DCMA4DC1R DC Milliammeter Specifications:
- Measurement Ranges: 300-1000 mA
- Measurement Accuracy: 0.8%
- Display Type: 3-1/2 digit LED, 11.4mm high
- Bar-graph Display: 21 segment, curved
- Power Supply: 9-32 VDC, typically 37 mA at 12V
- Input Voltage Range: +/-48V common-mode
- Operating Temperature: 0-50 °C
- Storage Temperature: -40-70 °C
- Humidity: 0-85 %RH
- Display Brightness: User adjustable via DIP switches
- Dimensions: Based on mechanical specifications, details in document
- Housing Material: Rugged polycarbonate
- Sealing: Splash and dust resistant
- Mounting: Drop-in, screw-mounted, #4-20 screws
- RoHS Compliant: Yes
- Warranty: Two years
- Input Protection: Overvoltage and reverse polarity protection
Buy the Buy Murata Power Solutions DMR35-DCxA Series Part Number DMR35DCMA4DC1R Online
Purchase the Murata DMR35-DCxA series DC milliammeter online to ensure precise DC current measurement with a bright LED display, adjustable brightness, low power consumption, and a rugged design. Easy to install as a drop-in replacement for analog meters, it offers 0.8% accuracy and supports measurement ranges from 300mA to 1A, powered by 9 to 32 VDC. Made with high-quality materials, it guarantees reliable operation in laboratory or industrial environments. Order now for quick delivery and enjoy excellent performance in your applications.
Buy Murata Power Solutions DMR35-DCxA4DC1R now and experience unmatched reliability and precise DC current measurement with adjustable display brightness.
