MURATA POWER SOLUTIONS MGJ2D052003SC Gate Drive Converter

Name: MGJ2D052003SC - Electronic Component
Brand: MURATA POWER SOLUTIONS
SKU: MGJ2D052003SC
Price: 8.7 USD
Availability: InStock
Rating: 5.0 (1 reviews)

The MGJ2 series of DC-DC converters by Murata Power Solutions offers high isolation of 5.2kVDC and is ideal for powering gate drive circuits in IGBT and MOSFET bridge applications. Designed for high efficiency and reliability, these 2W converters feature reinforced insulation, wide temperature ratings up to 100°C, and are recognized standards like UL60950 and ANSI/AAMI ES60601-1 pending. They support various input and output configurations, ensuring optimal drive levels, EMI performance, and long service life in industrial motor drives and inverters.

Murata Series MGJ2 5.2kVDC Isolated Gate Drive Converter: MGJ2D052003SC

View MGJ2D052003SCDatasheet [pdf]

MURATA POWER SOLUTIONS MGJ2D052003SC Gate Drive Converter Specifications:

Isolation Voltage: 5.2kVDC (tested at 1 second, qualified at 1 minute)
Power Rating: 2W
Input Voltage Range: 5V, 12V, 15V, 24V types
Output Voltage Options: -15V to +20V, various configurations
Efficiency: Up to 82%, typical 78-82%
Operating Temperature: -40°C to +100°C
Case Temperature: up to 100°C
Isolation Capacitance: Min 10.8pF, typ 12pF
Working Altitude: 400m
Fusing: External UL recognized fuse, rated 750mA or 1.25A depending on model
Compliance: UL60950, UL/ANSI AAMI ES60601-1 pending recognition
Dimensions and Mechanical: Refer to datasheet for pinout and mount details
Wave Solder Profile: Not to exceed IEC guidelines
Storage Temperature: -55°C to +125°C
Cooling: Free air convection
Certification: Pending UL recognition, RoHS compliant

Buy the Murata Series MGJ2 5.2kVDC Isolated Gate Drive Converter: MGJ2D052003SC

Enhance your industrial motor drive systems with the Murata MGJ2D052003SC. This 2W isolated DC-DC converter features 5.2kVDC high isolation, excellent efficiency, and compliance with safety standards. Designed for robust operation from -40°C to +100°C, it ensures long-term reliability in demanding environments. External UL-recognized fuses provide added protection. Easy to install with compact dimensions, the MGJ2 series supports various input/output configurations, making it an ideal solution for high-voltage gate drive circuits in inverter andConverter applications. Purchase online today for dependable performance.

Buy Murata MGJ2D052003SC now and experience unmatched reliability and performance in industrial power applications.
