MYRRA 47155 Electronic Transformer
The 47000 series electronic transformers are highly efficient, compact switched-mode power supplies based on flyback topology. Designed as alternatives to linear transformers, they support power applications up to 5W with energy savings and low standby power consumption. These transformers feature wide input voltage ranges (both AC and DC), high efficiency (around 70%), and comply with strict safety and EMC standards. Suitable for industrial, domestic, and consumer electronics, they replace traditional transformers, fuses, bridge rectifiers, and filtering capacitors, ensuring reliable, safe operation and easy PCB integration.
MYRRA 47155 Electronic Transformer Specifications:
- Input voltage range: 85 to 265 Volts AC, 85 to 370 Volts DC
- Input Frequency: 47 to 440 Hz
- Output voltage accuracy: +2% (regulated), +5% (non-regulated)
- Output Power: 3.2W and 5W (regulated), 3W and 5W (non-regulated), two common outputs
- Output voltage: 3.3V DC, 5V DC, and optional regulated outputs; maximum output current varies with model
- Efficiency: approximately 70%
- Standby power consumption: < 200mW (regulated), < 300mW (non-regulated)
- Dimensions: same footprint as EI30 transformer, detailed dimensions vary by model
- Safety: Meets EN 60950, EN 60335, EN 61558-2-17; UL listed components; reinforced insulation
- Isolation Voltage: 4000 Vac input/output; 4000 Vac between outputs for dual output models
- Operating temperature: -25°C to +70°C; Storage: -40°C to +85°C
- Protection: integrated fuse, short-circuit auto restart, thermal shutdown
Buy the Myrra Series 47000 Electronic Transformer: 47155
Discover the highly efficient and reliable Myrra 47000 series electronic transformer, offering wide input voltage compatibility, low standby power, and compliance with safety standards. Its compact design and easy PCB integration make it ideal for low power AC/DC applications, telecom power supplies, and domestic electronics. With high efficiency and multiple output options, this transformer ensures stable voltage regulation and energy savings. Purchase online today to enhance your project with a durable, safety-compliant power solution built for long-lasting performance.
Get Myrra 47155 electronic transformer today—designed for energy efficiency, safety, and reliable low power conversion in your application.
